59
HCD-GP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Q328 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q329 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q330 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q331 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q332 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q333 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q334 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q335 8-729-016-42 TRANSISTOR KTC3199GR-TP
< RESISTOR >
R130 1-249-417-11 CARBON 1K 5% 1/4W F
R131 1-249-431-11 CARBON 15K 5% 1/4W
R132 1-249-441-11 CARBON 100K 5% 1/4W
R134 1-249-438-11 CARBON 56K 5% 1/4W
0R141 1-215-890-11 METAL OXIDE 470 5% 2W
R230 1-249-417-11 CARBON 1K 5% 1/4W F
R231 1-249-431-11 CARBON 15K 5% 1/4W
R232 1-249-441-11 CARBON 100K 5% 1/4W
R234 1-249-437-11 CARBON 47K 5% 1/4W
0R241 1-215-890-11 METAL OXIDE 470 5% 2W
R354 1-249-429-11 CARBON 10K 5% 1/4W
R355 1-249-429-11 CARBON 10K 5% 1/4W
R356 1-249-429-11 CARBON 10K 5% 1/4W
R357 1-249-441-11 CARBON 100K 5% 1/4W
0R358 1-215-890-11 METAL OXIDE 470 5% 2W
R362 1-249-441-11 CARBON 100K 5% 1/4W
R363 1-249-441-11 CARBON 100K 5% 1/4W
R364 1-249-441-11 CARBON 100K 5% 1/4W
R365 1-249-421-11 CARBON 2.2K 5% 1/4W F
R366 1-249-425-11 CARBON 4.7K 5% 1/4W F
R367 1-249-441-11 CARBON 100K 5% 1/4W
R368 1-249-435-11 CARBON 33K 5% 1/4W
R369 1-249-433-11 CARBON 22K 5% 1/4W
R370 1-249-429-11 CARBON 10K 5% 1/4W
R371 1-249-429-11 CARBON 10K 5% 1/4W
R386 1-247-895-91 CARBON 470K 5% 1/4W
R951 1-249-417-11 CARBON 1K 5% 1/4W F
R952 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
A-4747-951-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C601 1-126-947-11 ELECT 47uF 20.00% 16V
C602 1-130-483-00 MYLAR 0.01uF 5% 50V
C604 1-130-495-00 MYLAR 0.1uF 5% 50V
C605 1-126-964-11 ELECT 10uF 20.00% 50V
C606 1-126-960-11 ELECT 1uF 20.00% 50V
C607 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C608 1-126-961-11 ELECT 2.2uF 20.00% 50V
C610 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C611 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C612 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C613 1-164-392-11 CERAMIC CHIP 390PF 10.00% 50V
C614 1-130-483-00 MYLAR 0.01uF 5% 50V
C630 1-126-933-11 ELECT 100uF 20.00% 16V
C632 1-126-964-11 ELECT 10uF 20.00% 50V
C633 1-126-964-11 ELECT 10uF 20.00% 50V
C634 1-126-964-11 ELECT 10uF 20.00% 50V
C635 1-126-960-11 ELECT 1uF 20.00% 50V
C639 1-126-964-11 ELECT 10uF 20.00% 50V
C640 1-126-947-11 ELECT 47uF 20.00% 16V
C641 1-126-961-11 ELECT 2.2uF 20.00% 50V
C642 1-137-150-11 MYLAR 0.01uF 5.00% 100V
C643 1-130-485-00 MYLAR 0.015uF 5% 50V
C644 1-130-481-00 MYLAR 0.0068uF 5% 50V
C645 1-130-481-00 MYLAR 0.0068uF 5% 50V
C646 1-130-486-00 MYLAR 0.018uF 10% 50V
C647 1-126-964-11 ELECT 10uF 20.00% 50V
C651 1-126-947-11 ELECT 47uF 20.00% 16V
C652 1-130-483-00 MYLAR 0.01uF 5% 50V
C654 1-130-495-00 MYLAR 0.1uF 5% 50V
C655 1-126-964-11 ELECT 10uF 20.00% 50V
C656 1-126-960-11 ELECT 1uF 20.00% 50V
C657 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C658 1-126-961-11 ELECT 2.2uF 20.00% 50V
C660 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C661 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C662 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C663 1-164-392-11 CERAMIC CHIP 390PF 10.00% 50V
C664 1-130-483-00 MYLAR 0.01uF 5% 50V
C681 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN602 1-770-516-31 CONNECTOR, FFC 8P
CN603 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D681 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC601 6-702-130-01 IC HA12237F
IC602 8-759-508-69 IC BA3126N
< JUMPER RESISTOR >
JR602 1-216-296-11 SHORT CHIP 0
< JUMPER RESISTOR >
JW630 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
L601 1-410-780-11 INDUCTOR 27MH
L651 1-410-780-11 INDUCTOR 27MH
< TRANSISTOR >
Q639 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q640 8-729-036-58 TRANSISTOR KRC102M-AT
Q641 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q642 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q643 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q680 8-729-036-58 TRANSISTOR KRC102M-AT
Q681 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q691 8-729-038-67 TRANSISTOR KRC102S
Q692 8-729-038-67 TRANSISTOR KRC102S
SUB-POWER TC
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
