HCD-GP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Q693 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q694 8-729-116-57 TRANSISTOR 2SB1068TP-K
< RESISTOR >
R601 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R603 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R605 1-216-841-11 METAL CHIP 47K 5% 1/10W
R606 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R607 1-216-833-11 METAL CHIP 10K 5% 1/10W
R608 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R610 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R611 1-216-837-11 METAL CHIP 22K 5% 1/10W
R630 1-216-857-11 METAL CHIP 1M 5% 1/10W
R631 1-216-837-11 METAL CHIP 22K 5% 1/10W
R632 1-216-821-11 METAL CHIP 1K 5% 1/10W
R633 1-216-833-11 METAL CHIP 10K 5% 1/10W
R635 1-216-809-11 METAL CHIP 100 5% 1/10W
R640 1-216-833-11 METAL CHIP 10K 5% 1/10W
R641 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R642 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0R644 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R645 1-216-836-11 METAL CHIP 18K 5% 1/10W
R646 1-216-836-11 METAL CHIP 18K 5% 1/10W
R647 1-216-837-11 METAL CHIP 22K 5% 1/10W
R648 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R652 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R653 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R655 1-216-841-11 METAL CHIP 47K 5% 1/10W
R656 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R658 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R660 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R661 1-216-837-11 METAL CHIP 22K 5% 1/10W
R680 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R681 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R682 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R683 1-216-819-11 METAL CHIP 680 5% 1/10W
R684 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R685 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R686 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R687 1-216-841-11 METAL CHIP 47K 5% 1/10W
R688 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R689 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R690 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R691 1-216-833-11 METAL CHIP 10K 5% 1/10W
R692 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R693 1-216-841-11 METAL CHIP 47K 5% 1/10W
R694 1-216-837-11 METAL CHIP 22K 5% 1/10W
R695 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV603 1-241-768-11 RES, ADJ, CARBON 220K
RV653 1-241-768-11 RES, ADJ, CARBON 220K
< TRANSFORMER >
T601 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
1-689-901-11 THR BOARD
**********
< CONNECTOR >
* CN992 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< THERMISTOR(POSITIVE) >
THP821 1-807-796-11 THERMISTOR
************************************************************
1-689-608-11 VOL BOARD
**********
< CAPACITOR >
C852 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C853 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< SWITCH >
S851 1-478-127-11 ENCODER, ROTARY (VOLUME)
************************************************************
MISCELLANEOUS
**************
6 1-698-792-11 FAN, DC
8 1-693-626-11 TUNER (FM/AM)
9 1-773-009-11 WIRE (FLAT TYPE)(15 CORE)
73 1-796-351-51 MECHANISM, SIGNAL CASSETTE
75 1-773-114-11 WIRE (FLAT TYPE)(19 CORE)
83 1-773-038-11 WIRE (FLAT TYPE)(17 CORE)
84 1-824-335-11 WIRE (FLAT TYPE)(8 CORE)
0102 1-769-744-52 CORD, POWER
173 1-782-817-11 WIRE (FLAT TYPE)(16 CORE)
0601 A-4735-357-A BASE ASSY, OP (KSM-213D)
0F901 1-533-465-11 FUSE, GLASS TUBE (DIA. 5)(T1AL/250V)
0F904 1-533-468-11 FUSE, GLASS TUBE (DIA. 5)(T2AL/250V)
M901 A-4735-337-A MOTOR (LD) ASSY (LOADING)
0T901 1-443-037-11 POWER TRANSFORMER
THR
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
