HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. RE-
PLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
MHC-GTR6 (HCD-GTR6/HCD-GTR6B)
The following are measured at
AC 120, 220, 240 V, 50/60 Hz
Front/Surround speaker
Power Output (rated): 200 W + 200 W (at 4 Ω, 1 kHz, 1% THD, at LINK MODE)
Front speaker
RMS output power (reference):
225 W + 225 W (per channel at 8 Ω, 1 kHz, 10% THD)
Surround speaker
RMS output power (reference):
225 W + 225 W (per channel at 8 Ω, 1 kHz, 10% THD)
Inputs
VIDEO (AUDIO IN) L/R:
Voltage 250 mV, impedance 47 kilohms
PC IN L/R: Voltage 700 mV, impedance 47 kilohms
MIC: Sensitivity 1 mV, impedance 10 kilohms
(USB) port: Type A
Outputs
PHONES: Accepts headphones of 8 Ω or more
Disc player section
System Compact disc and digital audio system
Laser Diode Properties Emission Duration: Continuous
Laser Output*: Less than 44.6 µW
* This output is the value measurement
at a distance of 200 mm from the
objective lens surface on the Optical
Pick-up Block with 7 mm aperture.
Frequency response 20 Hz – 20 kHz
Signal-to-noise ratio More than 90 dB
Dynamic range More than 88 dB
Tape deck section
(Except for Latin American and Mexican models)
Recording system 4-track 2-channel stereo
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
North American models:
87.5 – 108.0 MHz (100 kHz step)
Other models: 87.5 – 108.0 MHz (50 kHz step)
Antenna FM lead antenna
Antenna terminals 75 ohms unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range Pan-American and Oceanian models:
530 – 1,710 kHz (with the interval set at 10 kHz)
531 – 1,710 kHz (with the interval set at 9 kHz)
Other models: 530 – 1,610 kHz (with the interval set at 10 kHz)
531 – 1,602 kHz (with the interval set at 9 kHz)
Antenna AM loop antenna
Antenna terminals External antenna terminal
Intermediate frequency 450 kHz
USB section
Supported bit rate MP3 (MPEG 1 Audio Layer 3): 32 – 320 kbps, VBR
WMA: 48 – 192 kbps AAC: 48 – 320 kbps
Sampling frequencies MP3 (MPEG 1 Audio Layer 3): 32/44.1/48 kHz
WMA: 44.1 kHz
AAC: 44.1 kHz
Transfer speed Full-Speed
Supported USB device Mass Storage Class
Maximum current 500 mA
General
Power requirements
Mexican model: 127 V AC, 60 Hz
Australian model: 230 – 240 V AC, 50/60 Hz
Argentina model: 220 V AC, 50/60 Hz
Other models: 120 V, 220 V or 230 – 240 V AC, 50/60 Hz,
adjustable with voltage selector
Power consumption MHC-GTR8: 460 W
MHC-GTR7: 440 W
MHC-GTR6: 300 W
Dimensions (w/h/d) (Approx.)
HCD-GTR8/HCD-GTR8B/
HCD-GTR7/
HCD-GTR6/HCD-GTR6B: 295x380x457mm
Mass (Approx.) HCD-GTR8B: 16.5 kg
HCD-GTR8/HCD-GTR7: 15.8 kg
HCD-GTR6B: 14.5 kg
HCD-GTR6: 13.8 kg
Design and specifi cations are subject to change without notice.
• Standby power consumption: 0.5 W
• Halogenated fl ame retardants are not
used in the certain printed wiring boards.
