HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
SECTION 7
ELECTRICAL PARTS LIST
CD SW BOARD
************
< CONNECTOR >
CN901 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< RESISTOR >
R991 1-216-837-11 METAL CHIP 22K 5% 1/10W
R992 1-216-835-11 METAL CHIP 15K 5% 1/10W
R993 1-216-833-11 METAL CHIP 10K 5% 1/10W
R994 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R995 1-216-839-11 METAL CHIP 33K 5% 1/10W
< SWITCH >
S950 1-771-410-21 SWITCH, TACTILE (EX-CHANGE/DISC SKIP)
S951 1-771-410-21 SWITCH, TACTILE (DISC 1)
S952 1-771-410-21 SWITCH, TACTILE (DISC 2)
S953 1-771-410-21 SWITCH, TACTILE (DISC 3)
S954 1-771-410-21 SWITCH, TACTILE (OPEN/CLOSE)
************************************************************
DISPLAY BOARD
*************
< CAPACITOR >
C901 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C903 1-163-077-00 CERAMIC CHIP 0.1uF 50V
C904 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C905 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C906 1-126-176-11 ELECT 220uF 20% 10V
C907 1-124-584-00 ELECT 100uF 20% 6.3V
C910 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C911 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C912 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C913 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1056 1-126-969-11 ELECT 220uF 20% 50V
C1125 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AUS)
< CONNECTOR >
CN902 1-784-784-11 CONNECTOR, FFC 23P
< DIODE >
D900 8-719-060-27 DIODE SLR-325MCT31
D901 6-502-469-01 DIODE SLI-325URT31
D902 6-502-244-01 DIODE KDZTR2.7B
< IC >
IC900 6-711-556-01 IC NJL24H400B-SA
< FLUORESCENT INDICATOR TUBE >
ND900 1-483-082-11 VACUUM FLUORESCENT DISPLAYS
< TRANSISTOR >
Q900 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q901 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q902 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q903 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R900 1-216-817-11 METAL CHIP 470 5% 1/10W
R901 1-216-821-11 METAL CHIP 1K 5% 1/10W
R902 1-216-821-11 METAL CHIP 1K 5% 1/10W
R903 1-216-809-11 METAL CHIP 100 5% 1/10W
R904 1-216-001-00 METAL CHIP 10 5% 1/10W
R905 1-216-001-00 METAL CHIP 10 5% 1/10W
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R907 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R908 1-216-821-11 METAL CHIP 1K 5% 1/10W
R909 1-216-821-11 METAL CHIP 1K 5% 1/10W
R910 1-216-819-11 METAL CHIP 680 5% 1/10W
R911 1-216-817-11 METAL CHIP 470 5% 1/10W
R919 1-216-809-11 METAL CHIP 100 5% 1/10W
R920 1-216-809-11 METAL CHIP 100 5% 1/10W
R921 1-216-809-11 METAL CHIP 100 5% 1/10W
R922 1-216-809-11 METAL CHIP 100 5% 1/10W
R923 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R924 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R925 1-216-809-11 METAL CHIP 100 5% 1/10W
R926 1-216-809-11 METAL CHIP 100 5% 1/10W
R927 1-216-845-11 METAL CHIP 100K 5% 1/10W
R928 1-216-845-11 METAL CHIP 100K 5% 1/10W
R996 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R997 1-216-841-11 METAL CHIP 47K 5% 1/10W
R998 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1148 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1149 1-216-821-11 METAL CHIP 1K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference number,
please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Accessories are given in the last of this
parts list.
CD SW
• Abbreviation
E2 : 120V AC area in E model
E3 : 240V AC area in E model
E51 : Chilean and Peruvian model
AR : Argentina model
AUS : Australian model
MX : Mexican model
The components identifi ed by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specifi ed.
DISPLAY
