Sony HCD-GTR7 - Component Disassembly Procedures

7
HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
1-2. TAPE MECHANISM DECK (only for HCD-GTR6B/GTR8B)
Note : Follow the disassembly procedure in the numerical order given.
1-1. CASE (TOP)

 two screws
(case 3 TP2)
 two screws
(case 3 TP2)

one screw
(case 3 TP2)



RT
two screws
(+BVTP 3 x 8)
 two screws
(+BVTP 3 x 8)
RB two screws
(+BVTP 3 x 8)
RI case (top)
 wire (flat type) (9 core)
(CN040)
 panel (side-R)
 panel (side-L)
one screw
(case 3 TP2)
 CN020 (8P)
(TC CASE TOP only for
HCD-GTR6B/ GTR8B)
 wire (flat type) (9 core)
(CN040)
 CN020 (8P)
b
b
a
a
RG
RH
RK
RE

one screw
(+BVTP 2.6 (3CR))

SHIELD PLATE (TOP)
(GTR6B/GTR8B)

four screws
(+BVTP 2.6 (3CR))

one screw
(+BVTP 2.6 (3CR))

one screw
(+BVTP 2.6 (3CR))

SHIELD PLATE (TCM)
(GTR6B/GTR8B)

tape mechanism deck
(TC CASE TOP only for
HCD-GTR6B/ GTR8B)
