Sony HCD-GTR7 - Page 82

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
82
HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
JR103 1-216-296-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-296-11 SHORT CHIP 0
JR107 1-216-296-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
JR110 1-216-296-11 SHORT CHIP 0
JR111 1-216-864-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR113 1-216-864-11 SHORT CHIP 0
JR114 1-216-864-11 SHORT CHIP 0
JR115 1-216-864-11 SHORT CHIP 0
JR116 1-216-296-11 SHORT CHIP 0
JR117 1-216-296-11 SHORT CHIP 0
JR118 1-216-296-11 SHORT CHIP 0
JR119 1-216-864-11 SHORT CHIP 0
JR122 1-216-296-11 SHORT CHIP 0
JR123 1-216-296-11 SHORT CHIP 0
JR124 1-216-864-11 SHORT CHIP 0
JR125 1-216-864-11 SHORT CHIP 0
JR126 1-216-864-11 SHORT CHIP 0
JR129 1-216-864-11 SHORT CHIP 0
JR130 1-216-864-11 SHORT CHIP 0
JR131 1-216-864-11 SHORT CHIP 0
JR133 1-216-864-11 SHORT CHIP 0
JR192 1-216-864-11 SHORT CHIP 0
JR315 1-216-864-11 SHORT CHIP 0 (GTR6B/GTR8B)
JR316 1-216-864-11 SHORT CHIP 0 (GTR6B/GTR8B)
< COIL >
L082 1-457-747-11 INDUCTOR 100uH
L091 1-457-752-11 INDUCTOR 47uH
L096 1-457-747-11 INDUCTOR 100uH
< TRANSISTOR >
Q001 8-729-920-79 TRANSISTOR 2SB1132-T100-QR
(GTR6B/GTR8B)
Q002 8-729-920-79 TRANSISTOR 2SB1132-T100-QR
(GTR6B/GTR8B)
Q003 8-729-038-28 TRANSISTOR RT1N441C-TP-1
(GTR6B/GTR8B)
Q004 8-729-038-28 TRANSISTOR RT1N441C-TP-1
(GTR6B/GTR8B)
Q005 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q006 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q007 8-729-037-13 TRANSISTOR KTA1271Y
Q008 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q009 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q021 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q030 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q031 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q032 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q033 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q034 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q036 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR7/GTR8/GTR8B)
Q037 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR7/GTR8/GTR8B)
Q038 8-729-040-76 TRANSISTOR KTA1273-Y-AT
(GTR7/GTR8/GTR8B)
Q039 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR7/GTR8/GTR8B)
Q113 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(GTR6B/GTR8B)
Q128 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q178 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q210 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q245 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR7/GTR8/GTR8B)
Q250 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q270 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q290 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q295 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR8/GTR8B)
Q300 8-729-036-86 TRANSISTOR KTC3203Y-AT (GTR6B/GTR8B)
Q301 8-729-037-13 TRANSISTOR KTA1271Y (GTR6B/GTR8B)
Q302 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR6B/GTR8B)
Q401 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR6B/GTR8B)
Q402 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR6B/GTR8B)
Q403 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR6B/GTR8B)
Q404 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR6B/GTR8B)
Q405 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(GTR6B/GTR8B)
Q406 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(GTR6B/GTR8B)
Q407 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(GTR6B/GTR8B)
Q408 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR6B/GTR8B)
Q409 8-729-027-43 TRANSISTOR DTC114EKA-T146
(GTR6B/GTR8B)
Q410 6-551-276-01 TRANSISTOR RT1N431C-TP-1
(GTR6B/GTR8B)
Q456 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(GTR6B/GTR8B)
Q500 6-551-276-01 TRANSISTOR RT1N431C-TP-1
Q501 8-729-027-26 TRANSISTOR DTA114YKA-T146
Q532 6-551-681-01 TRANSISTOR RT1P431C-TP-1
Q601 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q696 8-729-032-94 TRANSISTOR 2SD1859TV2Q
Q700 8-729-032-94 TRANSISTOR 2SD1859TV2Q
Q710 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q711 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q712 6-551-451-01 TRANSISTOR 2SB1690TL
Q713 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q714 6-551-451-01 TRANSISTOR 2SB1690TL
Q717 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q718 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q719 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q720 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q788 8-729-924-99 TRANSISTOR 2SC3722K-E
(GTR7/GTR8/GTR8B)
Q789 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR7/GTR8/GTR8B)
< RESISTOR >
R001 1-216-837-11 METAL CHIP 22K 5% 1/10W
(GTR6B/GTR8B)
R002 1-216-833-11 METAL CHIP 10K 5% 1/10W
(GTR6B/GTR8B)
MAIN
