HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MIC RV
< DIODE >
D1002 6-500-848-01 DIODE MC2840-T112-1
D1004 1-822-757-11 DIODE MC2840-T112-1
< IC >
IC1000 8-759-278-58 IC NJM4558V-TE2
< JACK >
J1001 1-764-767-21 JACK, PIN 2P (AUDIO INPUT LR)
J1004 1-817-629-11 JACK (LARGE TYPE) (MIC)
< JUMPER RESISTOR >
JR1021 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R1000 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1001 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1003 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1004 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1009 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1010 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1011 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1012 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1013 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1019 1-216-818-11 METAL CHIP 560 5% 1/10W
R1020 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R1021 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1022 1-216-809-11 METAL CHIP 100 5% 1/10W
R1023 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1025 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1026 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
MIC RV BOARD
************
< VARIABLE RESISTOR >
RV1001 1-227-452-11 RES, VAR, CARBON (MIC LEVEL) 50K
************************************************************
MOTOR (TB) BOARD
****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
************************************************************
MOTOR (LD) BOARD
****************
************************************************************
SENSOR BOARD
*************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 6-600-564-01 IC RPI-579N1
************************************************************
STR BOARD
**********
< CAPACITOR >
C920 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C921 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C922 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C923 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C925 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C926 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN903C 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
< DIODE >
D919 8-719-060-27 DIODE SLR-325MCT31 (GTR7/GTR8/GTR8B)
D920 6-502-469-01 DI SLI-325URT31
D921 6-502-469-01 DI SLI-325URT31
D922 6-502-469-01 DI SLI-325URT31
D923 6-502-468-01 DI 1L034FV22D0DAC09
D924 6-502-468-01 DI 1L034FV22D0DAC09
D925 6-502-468-01 DI 1L034FV22D0DAC09
D926 6-502-468-01 DI 1L034FV22D0DAC09
D927 6-502-468-01 DI 1L034FV22D0DAC09
D928 6-502-468-01 DI 1L034FV22D0DAC09
D929 6-502-469-01 DI SLI-325URT31
D930 6-502-469-01 DI SLI-325URT31
D931 6-502-469-01 DI SLI-325URT31
< IC >
IC901 6-713-768-01 IC R8A66166SP
< RESISTOR >
R929 1-216-819-11 METAL CHIP 680 5% 1/10W
(GTR7/GTR8/GTR8B)
R931 1-216-819-11 METAL CHIP 680 5% 1/10W
R933 1-216-819-11 METAL CHIP 680 5% 1/10W
R935 1-216-819-11 METAL CHIP 680 5% 1/10W
R937 1-216-817-11 METAL CHIP 470 5% 1/10W
R938 1-216-817-11 METAL CHIP 470 5% 1/10W
R939 1-216-819-11 METAL CHIP 680 5% 1/10W
R940 1-216-819-11 METAL CHIP 680 5% 1/10W
R941 1-216-821-11 METAL CHIP 1K 5% 1/10W
R942 1-216-821-11 METAL CHIP 1K 5% 1/10W
R943 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R944 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R945 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R946 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R947 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R948 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R949 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R950 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R951 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R952 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R953 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R954 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R955 1-216-833-11 METAL CHIP 10K 5% 1/10W
R956 1-216-833-11 METAL CHIP 10K 5% 1/10W
MOTOR(TB)
MIC CD
MOTOR(LD)
STR
SENSOR
