Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
90
HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
USB CD
R890 1-216-835-11 METAL CHIP 15K 5% 1/10W
(GTR8/GTR8B)
R890 1-216-837-11 METAL CHIP 22K 5% 1/10W
(GTR7/GTR8)
R891 1-216-848-11 METAL CHIP 180K 5% 1/10W
(GTR8)
R891 1-216-850-11 METAL CHIP 270K 5% 1/10W
(GTR7)
R893 1-216-841-11 METAL CHIP 47K 5% 1/10W
(GTR7)
R804 1-217-637-55 FUSIBLE 1 5% 1/4W
R810 1-216-840-11 METAL CHIP 39K 5% 1/10W
R814 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R827 1-245-605-55 FUSIBLE 100 5% 1/4W
R828 1-245-605-55 FUSIBLE 100 5% 1/4W
R830 1-245-711-31 CARBON 10 5% 1/2W
R838 1-220-893-11 METAL 0.22 10% 5W
R841 1-216-845-11 METAL CHIP 100K 5% 1/10W
R860 1-216-841-11 METAL CHIP 47K 5% 1/10W
R867 1-246-024-21 METAL CHIP 150 5% 1/2W
R880 1-245-711-31 CARBON 10 5% 1/2W
R888 1-220-893-11 METAL 0.22 10% 5W
R891 1-216-845-11 METAL CHIP 100K 5% 1/10W
< RELAY >
RY862 1-755-307-21 RELAY
< TERMINAL >
TB801 1-820-067-11 TERMINAL BOARD
(SPEAKER, SUBWOOFER OUT RL)
(GTR8/GTR8B)
TB802 1-780-473-11 TERMINAL BOARD (SPEAKER) 1P (GTR7)
************************************************************
SW BOARD
*********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE
Z
)
************************************************************
TRANS BOARD
************
< CAPACITOR >
C1252 1-126-964-11 ELECT 10uF 20% 50V
C1253 1-128-563-11 ELECT 100uF 20% 100V
C1254 1-126-968-11 ELECT 100uF 20% 50V
C1255 1-126-767-11 ELECT 1000uF 20% 16V
< CONNECTOR >
CN1250 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D1250 6-501-785-01 DIODE MAZ8200GMLS0
D1251 6-501-788-01 DIODE MAZ8240G0LS0
D1252 6-500-522-21 DIODE 10EDB40-TB3
D1253 6-500-522-21 DIODE 10EDB40-TB3
D1254 6-500-522-21 DIODE 10EDB40-TB3
D1255 6-500-522-21 DIODE 10EDB40-TB3
D1256 6-500-522-21 DIODE 10EDB40-TB3
< FUSE >
F1271 1-523-087-11 FUSE 4A 250V (T4AL/250V)
F1281 1-523-084-11 FUSE 2A 250V (T2AL/250V)
< HOLDER, FUSE >
FH1230 1-533-217-41 HOLDER, FUSE
FH1232 1-533-217-41 HOLDER, FUSE
FH1240 1-533-217-41 HOLDER, FUSE
FH1242 1-533-217-41 HOLDER, FUSE
FH1250 1-533-217-41 HOLDER, FUSE
FH1252 1-533-217-41 HOLDER, FUSE
FH1260 1-533-217-41 HOLDER, FUSE
FH1262 1-533-217-41 HOLDER, FUSE
< TRANSISTOR >
Q1250 8-729-032-94 TRANSISTOR 2SD1859TV2Q
< RESISTOR >
R1250 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1251 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1271 1-219-124-55 FUSIBLE 0.68 5% 1/4W
************************************************************
USB CD BOARD
*************
< CAPACITOR >
C1043 1-126-176-11 ELECT 220uF 20% 10V
C1044 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1045 1-126-176-11 ELECT 220uF 20% 10V
C1046 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1047 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1048 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN1000 1-819-866-11 CONNECTOR, USB (A)
CN1001 1-819-866-11 CONNECTOR, USB (A)
< DIODE >
D1020 6-501-691-01 DIODE 1L434FV22D0TDF01
D1021 6-502-517-01 DI 1L434FB12E0MDTZ1
D1022 6-502-517-01 DI 1L434FB12E0MDTZ1
D1023 6-501-743-01 DIODE MAZ8068GMLS0
D1024 6-501-743-01 DIODE MAZ8068GMLS0
D1025 6-501-743-01 DIODE MAZ8068GMLS0
D1026 6-500-848-01 DIODE MC2840-T112-1
D1027 6-500-848-01 DIODE MC2840-T112-1
D1030 6-500-848-01 DIODE MC2840-T112-1
D1031 6-501-743-01 DIODE MAZ8068GMLS0
D1032 6-500-848-01 DIODE MC2840-T112-1
D1033 6-500-848-01 DIODE MC2840-T112-1
D1034 6-501-743-01 DIODE MAZ8068GMLS0
D1035 6-501-743-01 DIODE MAZ8068GMLS0
D1038 6-500-848-01 DIODE MC2840-T112-1
< RESISTOR >
R1041 1-216-819-11 METAL CHIP 680 5% 1/10W
R1043 1-216-819-11 METAL CHIP 680 5% 1/10W
R1045 1-216-819-11 METAL CHIP 680 5% 1/10W
R1046 1-216-839-11 METAL CHIP 33K 5% 1/10W
SW
TRANS
SUBWOOFER
