Sony HCD-MG110 - Page 70

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
70
HCD-MG110/MG310AV
R508 1-249-417-11 CARBON 1K 5% 1/4W
R509 1-249-417-11 CARBON 1K 5% 1/4W
0 R510 1-215-891-11 METAL OXIDE 680 5% 2W F
R512 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AUS)
R513 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R514 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R516 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AUS)
R518 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AUS)
R519 1-216-841-11 METAL CHIP 47K 5% 1/16W
R520 1-216-841-11 METAL CHIP 47K 5% 1/16W
R522 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AUS)
0 R523 1-215-892-11 METAL OXIDE 1K 5% 2W F
R524 1-249-401-11 CARBON 47 5% 1/4W
R525 1-249-401-11 CARBON 47 5% 1/4W
R526 1-249-401-11 CARBON 47 5% 1/4W
R527 1-249-401-11 CARBON 47 5% 1/4W
0 R528 1-215-892-11 METAL OXIDE 1K 5% 2W F
(MG310AV)
R529 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AUS)
R531 1-216-837-11 METAL CHIP 22K 5% 1/16W
R532 1-216-837-11 METAL CHIP 22K 5% 1/16W
R533 1-216-837-11 METAL CHIP 22K 5% 1/16W
(MG310AV)
R534 1-216-837-11 METAL CHIP 22K 5% 1/16W
(MG310AV)
R535 1-216-845-11 METAL CHIP 100K 5% 1/16W
R536 1-216-845-11 METAL CHIP 100K 5% 1/16W
0 R537 1-215-892-11 METAL OXIDE 1K 5% 2W F
(MG310AV)
R539 1-216-845-11 METAL CHIP 100K 5% 1/16W
R540 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R542 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
0 R544 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R545 1-216-821-11 METAL CHIP 1K 5% 1/16W
R546 1-216-835-11 METAL CHIP 15K 5% 1/16W
R547 1-216-835-11 METAL CHIP 15K 5% 1/16W
R548 1-216-821-11 METAL CHIP 1K 5% 1/16W
0 R551 1-212-881-11 FUSIBLE 100 5% 1/4W F
R552 1-216-841-11 METAL CHIP 47K 5% 1/16W
R553 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R554 1-212-881-11 FUSIBLE 100 5% 1/4W F
R555 1-249-425-11 CARBON 4.7K 5% 1/4W
R557 1-216-841-11 METAL CHIP 47K 5% 1/16W
R558 1-216-821-11 METAL CHIP 1K 5% 1/16W
R559 1-216-821-11 METAL CHIP 1K 5% 1/16W
R560 1-249-429-11 CARBON 10K 5% 1/4W
R561 1-216-841-11 METAL CHIP 47K 5% 1/16W
R562 1-216-841-11 METAL CHIP 47K 5% 1/16W
R563 1-216-841-11 METAL CHIP 47K 5% 1/16W
R564 1-216-821-11 METAL CHIP 1K 5% 1/16W
R565 1-216-821-11 METAL CHIP 1K 5% 1/16W
R601 1-249-417-11 CARBON 1K 5% 1/4W
(MG310AV)
R602 1-216-833-11 METAL CHIP 10K 5% 1/16W
(MG310AV)
R603 1-216-833-11 METAL CHIP 10K 5% 1/16W
(MG310AV)
R604 1-249-429-11 CARBON 10K 5% 1/4W
(MG310AV)
R605 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(MG310AV)
R606 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(MG310AV)
R607 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
R608 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
R609 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R610 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R611 1-249-417-11 CARBON 1K 5% 1/4W
(MG310AV)
R612 1-216-833-11 METAL CHIP 10K 5% 1/16W
(MG310AV)
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(MG310AV)
R614 1-216-833-11 METAL CHIP 10K 5% 1/16W
(MG310AV)
0 R615 1-212-881-11 FUSIBLE 100 5% 1/4W F
(MG310AV)
R616 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R617 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
0 R618 1-212-881-11 FUSIBLE 100 5% 1/4W F
(MG310AV)
R619 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
R620 1-216-835-11 METAL CHIP 15K 5% 1/16W
(MG310AV)
R621 1-216-835-11 METAL CHIP 15K 5% 1/16W
(MG310AV)
R622 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
0 R623 1-233-352-41 ENCAPSULATED COMPONENT 0.22 5W
(MG310AV)
R624 1-216-833-11 METAL CHIP 10K 5% 1/16W
(MG310AV)
R625 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
0 R626 1-233-352-41 ENCAPSULATED COMPONENT 0.22 5W
(MG310AV)
R627 1-216-845-11 METAL CHIP 100K 5% 1/16W
(MG310AV)
R628 1-216-845-11 METAL CHIP 100K 5% 1/16W
(MG310AV)
R629 1-249-401-11 CARBON 47 5% 1/4W
(MG310AV)
R630 1-249-401-11 CARBON 47 5% 1/4W
(MG310AV)
R631 1-249-401-11 CARBON 47 5% 1/4W
(MG310AV)
R632 1-249-401-11 CARBON 47 5% 1/4W
(MG310AV)
MAIN AMP
Ver 1.1
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
