HCD-MG110/MG310AV
R634 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
R635 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R636 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
R638 1-216-841-11 METAL CHIP 47K 5% 1/16W
(MG310AV)
R639 1-216-835-11 METAL CHIP 15K 5% 1/16W
(MG310AV)
R640 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MG310AV)
0 R642 1-233-352-41 ENCAPSULATED COMPONENT 0.22 5W
(MG310AV)
R643 1-216-845-11 METAL CHIP 100K 5% 1/16W
(MG310AV)
R644 1-249-401-11 CARBON 47 5% 1/4W
(MG310AV)
R645 1-249-401-11 CARBON 47 5% 1/4W
(MG310AV)
< RELAY >
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V) (MG310AV)
RY503 1-515-920-11 RELAY (24V) (MG310AV)
**************************************************************
1-680-803-11 POWER BOARD (MG110)
1-680-803-21 POWER BOARD (MG310AV)
*************
1-533-233-31 HOLDER, FUSE
1-535-416-00 TERMINAL
< CAPACITOR >
C901 1-126-968-11 ELECT 100uF 20% 50V
C902 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C903 1-126-767-11 ELECT 1000uF 20% 16V
C913 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C914 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
0 C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
D913 8-719-991-33 DIODE 1SS133T-77
D914 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0 F901 1-533-449-11 FUSE, GLASS TUBE (DIA. 5) (2A/125V)
(US, CND, MX)
0 F901 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) (2A/250V) (AUS)
0 F902 1-533-451-11 FUSE, GLASS TUBE (DIA. 5) (3.15/125V)
(US, CND, MX)
0 F902 1-533-467-11 FUSE, GLASS TUBE (DIA. 5) (1.6A/250V)
(AUS)
< LINE FILTER >
0 LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< TRANSISTOR >
Q901 8-729-036-77 TRANSISTOR KRC107M-AT
< RESISTOR >
0 R901 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R902 1-219-237-11 SOLID 3.3M 20% 1/2W
(US, CND, MX)
< RELAY >
0 RY901 1-755-332-11 RELAY
< TRANSFORMER >
0 T901 1-437-287-11 TRANSFORMER, POWER (MG110)
0 T901 1-437-288-11 TRANSFORMER, POWER
(MG310AV: US, CND)
0 T901 1-473-291-11 TRANSFORMER, POWER (AUS)
0 T902 1-437-292-11 TRANSFORMER, POWER (US, CND, MX)
0 T902 1-437-293-11 TRANSFORMER, POWER (AUS)
**************************************************************
1-680-809-11 RMC BOARD
**********
< IC >
IC702 8-759-827-70 IC NJL64H400A-1
**************************************************************
A-4476-373-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C401 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C402 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C403 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C404 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C405 1-126-934-11 ELECT 220uF 20% 10V
C406 1-130-486-00 MYLAR 0.018uF 10% 50V
C408 1-126-947-11 ELECT 47uF 20% 10V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C410 1-126-963-11 ELECT 4.7uF 20% 50V
C411 1-126-947-11 ELECT 47uF 20% 10V
C412 1-126-961-11 ELECT 2.2uF 20% 50V
C414 1-126-947-11 ELECT 47uF 20% 10V
C415 1-126-947-11 ELECT 47uF 20% 10V
C416 1-126-963-11 ELECT 4.7uF 20% 50V
C417 1-126-963-11 ELECT 4.7uF 20% 50V
C418 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C419 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C420 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C421 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C422 1-126-960-11 ELECT 1uF 20% 50V
C423 1-126-960-11 ELECT 1uF 20% 50V
C424 1-126-960-11 ELECT 1uF 20% 50V
C425 1-104-665-11 ELECT 100uF 20% 10V
C426 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C427 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C428 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C429 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
