Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
72
HCD-MG110/MG310AV
C430 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C431 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C432 1-130-483-00 MYLAR 0.01uF 5% 50V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 10V
C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C436 1-130-481-00 MYLAR 0.0068uF 5% 50V
C437 1-126-934-11 ELECT 220uF 20% 10V
C438 1-130-486-00 MYLAR 0.018uF 10% 50V
C439 1-104-665-11 ELECT 100uF 20% 10V
C441 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C442 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C443 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C444 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN401 1-695-371-31 CONNECTOR, FFC 10P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
< IC >
IC401 8-759-242-58 IC TA8189N
IC402 8-759-143-54 IC uPC1330HA
< TRANSISTOR >
Q401 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q402 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q403 8-729-038-67 TRANSISTOR KRC102S
Q404 8-729-036-89 TRANSISTOR KTC3198GR-A
Q405 8-729-036-89 TRANSISTOR KTC3198GR-A
< RESISTOR >
R401 1-216-821-11 METAL CHIP 1K 5% 1/16W
R402 1-216-821-11 METAL CHIP 1K 5% 1/16W
R403 1-216-821-11 METAL CHIP 1K 5% 1/16W
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R405 1-216-809-11 METAL CHIP 100 5% 1/16W
R406 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R407 1-216-848-11 METAL CHIP 180K 5% 1/16W
R408 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R409 1-216-809-11 METAL CHIP 100 5% 1/16W
R410 1-216-848-11 METAL CHIP 180K 5% 1/16W
R411 1-216-845-11 METAL CHIP 100K 5% 1/16W
R412 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R413 1-216-848-11 METAL CHIP 180K 5% 1/16W
R414 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R415 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R416 1-216-833-11 METAL CHIP 10K 5% 1/16W
R417 1-216-805-11 METAL CHIP 47 5% 1/16W
R418 1-216-845-11 METAL CHIP 100K 5% 1/16W
R419 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R420 1-216-848-11 METAL CHIP 180K 5% 1/16W
R421 1-216-857-11 METAL CHIP 1M 5% 1/16W
R422 1-216-833-11 METAL CHIP 10K 5% 1/16W
R423 1-216-857-11 METAL CHIP 1M 5% 1/16W
R424 1-216-801-11 METAL CHIP 22 5% 1/16W
R425 1-216-841-11 METAL CHIP 47K 5% 1/16W
R426 1-216-845-11 METAL CHIP 100K 5% 1/16W
R427 1-216-809-11 METAL CHIP 100 5% 1/16W
R428 1-216-835-11 METAL CHIP 15K 5% 1/16W
R429 1-216-835-11 METAL CHIP 15K 5% 1/16W
R430 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R431 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R432 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R433 1-216-805-11 METAL CHIP 47 5% 1/16W
R434 1-216-803-11 METAL CHIP 33 5% 1/16W
R435 1-216-833-11 METAL CHIP 10K 5% 1/16W
R436 1-216-797-11 METAL CHIP 10 5% 1/16W
R437 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R438 1-216-841-11 METAL CHIP 47K 5% 1/16W
R439 1-216-837-11 METAL CHIP 22K 5% 1/16W
R441 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R443 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R444 1-216-819-11 METAL CHIP 680 5% 1/16W
R445 1-216-819-11 METAL CHIP 680 5% 1/16W
< TRANSFORMER/COIL >
T401 1-433-372-11 TRANSFORMER, BIAS OSCILLATION
T402 1-419-080-11 COIL
T403 1-419-080-11 COIL
**************************************************************
1-680-817-11 T SENSOR BOARD (US, CND, MX)
1-680-817-21 T SENSOR BOARD (AUS)
***************
< PHOTO INTERRUPTER >
IC11 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC12 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC13 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R891 1-216-820-11 METAL CHIP 820 5% 1/16W
R892 1-216-820-11 METAL CHIP 820 5% 1/16W
R893 1-216-820-11 METAL CHIP 820 5% 1/16W
**************************************************************
MISCELLANEOUS
**************
4 1-823-005-11 WIRE (FLAT TYPE) (21CORE)
5 1-823-000-11 WIRE (FLAT TYPE) (18CORE)
6 1-757-997-11 WIRE (FLAT TYPE) (10CORE)
7 1-823-001-11 WIRE (FLAT TYPE) (11CORE)
8 1-823-004-11 WIRE (FLAT TYPE) (17CORE)
77 1-796-078-11 DECK, MECH
89 1-757-999-11 WIRE (FLAT TYPE) (13CORE)
0 105 1-757-933-11 CORD, POWER (US, CND)
0 105 1-823-003-11 CORD, POWER (AUS)
0 555 A-3328-818-A BASE ASSY (KSM-213BFN), OP
556 1-757-055-11 WIRE, PARALLEL (FFC) (16 CORE)
M51 A-4735-051-A MOTOR (60) ASSY (LOADING)
M52 A-4735-051-A MOTOR (60) ASSY (TABLE)
M101 X-2646-110-1 T.T CHASSIS ASSY (MG) (F) (SPINDLE)
M102 X-2625-769-1 MOTOR GEAR ASSY (MB) (RP) (SLED)
TC T SENSOR
Ver 1.3
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
