100
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< FERRITE BEAD >
FB1101 1-216-864-11 SHORT CHIP 0
FB1102 1-216-864-11 SHORT CHIP 0
FB1103 1-216-864-11 SHORT CHIP 0
FB1104 1-216-864-11 SHORT CHIP 0
FB1105 1-216-864-11 SHORT CHIP 0
FB1106 1-216-864-11 SHORT CHIP 0
< IC >
IC1101 6-705-602-01 IC MM1623BFBE
< JACK >
J1101 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J1102 1-785-867-11 JACK, PIN 1P (VIDEO OUT)
J1103 1-793-483-11 PHONO JACK 3P (COMPONENT OUT)
< COIL >
L1101 1-412-058-11 INDUCTOR 10uH
< TRANSISTOR >
Q1101 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1102 1-216-809-11 METAL CHIP 100 5% 1/10W
R1103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1104 1-218-285-11 METAL CHIP 75 5% 1/10W
R1105 1-218-285-11 METAL CHIP 75 5% 1/10W
R1106 1-218-285-11 METAL CHIP 75 5% 1/10W
R1107 1-218-285-11 METAL CHIP 75 5% 1/10W
R1108 1-218-285-11 METAL CHIP 75 5% 1/10W
R1109 1-216-809-11 METAL CHIP 100 5% 1/10W
R1110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1111 1-218-285-11 METAL CHIP 75 5% 1/10W
R1112 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
A-1063-580-A VOL BOARD, COMPLETE (TH)
A-4752-315-A VOL BOARD, COMPLETE (EXCEPT TH)
******************
< CAPACITOR >
C1007 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1008 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1013 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CN1050 1-784-776-11 CONNECTOR, FFC 15P
CN1051 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D1050 8-719-071-44 DIODE SELS5223C-TP15
D1051 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC1050 6-600-349-31 IC NJL24H400A
< TRANSISTOR >
Q1041 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1048 1-216-864-11 SHORT CHIP 0
R1049 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1050 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1059 1-216-805-11 METAL CHIP 47 5% 1/10W
R1090 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1091 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1092 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1093 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1094 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1095 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S1042 1-762-875-21 SWITCH, KEYBOARD (1/1)
S1043 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S1050 1-786-418-11 SWITCH, ROTARY (ENCODER) (SOUND MODE)
S1051 1-786-418-11 SWITCH, ROTARY (ENCODER)
(SOUND SELECT)
S1052 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
************************************************************
MISCELLANEOUS
*************
3 1-769-972-11 WIRE (FLAT TYPE) (13 CORE)
4 1-765-333-11 WIRE (FLAT TYPE) (15 CORE)
5 1-769-872-11 WIRE (FLAT TYPE) (5 CORE)
6 1-769-939-11 WIRE (FLAT TYPE) (11 CORE)
11 1-693-603-31 TUNER (FM/AM)
59 1-796-880-11 DECK, MECHANISM (W)
0 102 1-468-818-11 REGULATOR, SWITCHING
0 103 1-775-786-21 CORD, POWER (EA)
0 103 1-777-071-53 CORD, POWER (SP, MY)
0 103 1-824-818-11 CORD, POWER (WITH CONNECTOR) (TH)
0 103 1-827-226-11 CORD, POWER (E2, E3, E15)
109 1-500-497-11 FILTER, CLAMP (FERRITE CORE)
110 1-543-830-11 CLAMP, SELEEVE FERRITE
111 1-500-657-11 CORE, FERRITE (EXCEPT TH)
0 302 A-1067-676-A OPTICAL PICK-UP (DBU-3)
305 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
M761 A-4713-174-A MOTOR (81) ASSY (LD/ST MOTOR)
M762 A-4713-174-A MOTOR (81) ASSY (BU U/D MOTOR)
M961 1-787-099-11 FAN, DC
S771 1-478-552-11 ENCODER, ROTARY
S781 1-478-551-11 ENCODER, ROTARY
VOL
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
VIDEO
To Next Page
