Sony HCD-NXM2D - Page 99

99
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-922-01 IC SP3723CAF0PM
IC003 6-703-921-01 IC TL343IDBVR
< COIL >
L001 1-412-031-11 INDUCTOR 47uH
L002 1-412-031-11 INDUCTOR 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-P
Q002 8-729-903-46 TRANSISTOR 2SB1132-P
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/10W
R003 1-216-803-11 METAL CHIP 33 5% 1/10W
R004 1-216-803-11 METAL CHIP 33 5% 1/10W
R005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 SHORT CHIP 0
R012 1-216-864-11 SHORT CHIP 0
R013 1-216-864-11 SHORT CHIP 0
R014 1-216-864-11 SHORT CHIP 0
R015 1-216-864-11 SHORT CHIP 0
R016 1-216-864-11 SHORT CHIP 0
R017 1-216-864-11 SHORT CHIP 0
R018 1-216-864-11 SHORT CHIP 0
R019 1-216-864-11 SHORT CHIP 0
R020 1-216-864-11 SHORT CHIP 0
R021 1-216-864-11 SHORT CHIP 0
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 SHORT CHIP 0
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/10W
R027 1-216-864-11 SHORT CHIP 0
R028 1-216-864-11 SHORT CHIP 0
R029 1-216-864-11 SHORT CHIP 0
R031 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-845-11 METAL CHIP 100K 5% 1/10W
R034 1-216-817-11 METAL CHIP 470 5% 1/10W
R035 1-216-864-11 SHORT CHIP 0
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
R046 1-216-833-11 METAL CHIP 10K 5% 1/10W
R047 1-216-839-11 METAL CHIP 33K 5% 1/10W
R091 1-218-913-91 METAL CHIP 560K 0.5% 1/10W
************************************************************
SENSOR BOARD
************
< IC >
IC751 8-759-989-76 IC RPR-359F
************************************************************
SW (1) BOARD
***********
< SWITCH >
S721 1-786-084-11 SWITCH, DETECTION (MAIN TRY IN/OUT)
************************************************************
SW (2) BOARD
***********
< SWITCH >
S731 1-786-382-11 SWITCH, PUSH (1 KEY) (SUB TRY IN)
************************************************************
A-4752-312-A VIDEO BOARD, COMPLETE
*******************
< CAPACITOR >
C1101 1-126-960-11 ELECT 1uF 20% 50V
C1102 1-126-960-11 ELECT 1uF 20% 50V
C1103 1-126-960-11 ELECT 1uF 20% 50V
C1104 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1105 1-126-965-91 ELECT 22uF 20% 50V
C1106 1-126-960-11 ELECT 1uF 20% 50V
C1107 1-126-960-11 ELECT 1uF 20% 50V
C1108 1-126-960-11 ELECT 1uF 20% 50V
C1109 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1110 1-104-658-91 ELECT 100uF 20% 10V
C1111 1-126-916-11 ELECT 1000uF 20% 6.3V
C1112 1-126-916-11 ELECT 1000uF 20% 6.3V
C1113 1-126-916-11 ELECT 1000uF 20% 6.3V
C1114 1-126-916-11 ELECT 1000uF 20% 6.3V
C1115 1-126-916-11 ELECT 1000uF 20% 6.3V
C1116 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1117 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1118 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1119 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1120 1-216-864-11 SHORT CHIP 0
C1121 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1122 1-216-864-11 SHORT CHIP 0
C1123 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1124 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1125 1-216-864-11 SHORT CHIP 0
< CONNECTOR >
CN1101 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
< EARTH TERMINAL >
EP1101 1-537-738-21 TERMINAL, GROUND
EP1102 1-537-738-21 TERMINAL, GROUND
SENSOR SW (1) VIDEOSW (2)
RF
