98
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R1102 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S1021 1-762-875-21 SWITCH, KEYBOARD (DVD)
S1022 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S1023 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S1024 1-762-875-21 SWITCH, KEYBOARD (VIDEO (MD))
S1025 1-762-875-21 SWITCH, KEYBOARD (DIMMER)
S1026 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S1027 1-762-875-21 SWITCH, KEYBOARD (z START)
S1028 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1029 1-762-875-21 SWITCH, KEYBOARD (b B)
S1030 1-762-875-21 SWITCH, KEYBOARD (DVD Z)
S1031 1-762-875-21 SWITCH, KEYBOARD (X)
S1032 1-762-875-21 SWITCH, KEYBOARD (M > TUNING +)
S1033 1-762-875-21 SWITCH, KEYBOARD (. m TUNING -)
S1034 1-762-875-21 SWITCH, KEYBOARD (ALBUM +/DVD MENU)
S1035 1-762-875-21 SWITCH, KEYBOARD
(ALBUM -/DVD TOP MENU)
S1036 1-762-875-21 SWITCH, KEYBOARD (x)
< TRANSFORMER >
T801 1-443-285-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-4750-232-A RELAY BOARD, COMPLETE
*******************
< CAPACITOR >
C701 1-126-786-11 ELECT 47uF 20% 16V
C702 1-126-791-11 ELECT 10uF 20% 35V
C761 1-162-306-11 CERAMIC 0.01uF 20% 16V
C762 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN701 1-779-558-21 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
D711 8-719-982-10 DIODE MTZJ-4.3A
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q751 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-806-11 CARBON 91 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-430-11 CARBON 12K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
A-4728-690-A RF BOARD, COMPLETE
*****************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C037 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C050 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C051 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
PANEL
RELAY RF
