97
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R497 1-216-833-11 METAL CHIP 10K 5% 1/10W
R498 1-216-797-11 METAL CHIP 10 5% 1/10W
R499 1-216-797-11 METAL CHIP 10 5% 1/10W
R901 1-216-833-11 METAL CHIP 10K 5% 1/10W
R902 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R904 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R906 1-216-809-11 METAL CHIP 100 5% 1/10W
R907 1-216-837-11 METAL CHIP 22K 5% 1/10W
R908 1-216-809-11 METAL CHIP 100 5% 1/10W
R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
R914 1-216-821-11 METAL CHIP 1K 5% 1/10W
R915 1-216-821-11 METAL CHIP 1K 5% 1/10W
R952 1-216-809-11 METAL CHIP 100 5% 1/10W
R955 1-216-809-11 METAL CHIP 100 5% 1/10W
R956 1-216-809-11 METAL CHIP 100 5% 1/10W
R957 1-216-809-11 METAL CHIP 100 5% 1/10W
R958 1-216-809-11 METAL CHIP 100 5% 1/10W
R959 1-216-809-11 METAL CHIP 100 5% 1/10W
R969 1-216-833-11 METAL CHIP 10K 5% 1/10W
R970 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T301 1-433-372-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X401 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-795-482-11 VIBRATOR, CERAMIC (16MHz)
************************************************************
MOTOR BOARD
***********
< SWITCH >
S761 1-786-704-11 SWITCH, LEVER (SUB TRY OUT)
************************************************************
A-1063-578-A PANEL BOARD, COMPLETE (TH)
A-4752-675-A PANEL BOARD, COMPLETE (EXCEPT TH)
*******************
< CAPACITOR >
C1006 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1021 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1025 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1026 1-126-964-11 ELECT 10uF 20% 50V
C1028 1-126-964-11 ELECT 10uF 20% 50V
C1029 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1048 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1050 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1051 1-126-969-11 ELECT 220uF 20% 50V
C1052 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1053 1-126-965-91 ELECT 22uF 20% 50V
C1054 1-162-995-11 CERAMIC CHIP 0.022uF 50V
< CONNECTOR >
CN1021 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D1021 8-719-058-03 DIODE SEL5423E-TP15
D1022 8-719-059-18 DIODE RD6.2FM-T1
D1023 8-719-988-61 DIODE 1SS355TE-17
D1024 8-719-988-61 DIODE 1SS355TE-17
D1025 8-719-988-61 DIODE 1SS355TE-17
D1026 8-719-988-61 DIODE 1SS355TE-17
< FLUORESCENT INDICATOR >
FL1020 1-518-979-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC1020 6-705-745-01 IC M66005-0131AHPRB0T
< COIL >
L1021 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q1021 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1022 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1023 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1024 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q1026 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1020 1-216-809-11 METAL CHIP 100 5% 1/10W
R1021 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1022 1-216-809-11 METAL CHIP 100 5% 1/10W
R1023 1-216-809-11 METAL CHIP 100 5% 1/10W
R1024 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1025 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1026 1-216-813-11 METAL CHIP 220 5% 1/10W
R1027 1-216-815-11 METAL CHIP 330 5% 1/10W
R1028 1-216-817-11 METAL CHIP 470 5% 1/10W
R1029 1-216-819-11 METAL CHIP 680 5% 1/10W
R1030 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1031 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1032 1-216-864-11 SHORT CHIP 0
R1033 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1034 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1035 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1036 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1037 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1038 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1039 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1040 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1041 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1042 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1043 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1045 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1046 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1051 1-216-809-11 METAL CHIP 100 5% 1/10W
R1052 1-216-809-11 METAL CHIP 100 5% 1/10W
R1096 1-215-871-11 METAL OXIDE 2.2K 5% 1W
R1100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1101 1-216-833-11 METAL CHIP 10K 5% 1/10W
MAIN MOTOR PANEL
To Next Page
