88
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R751 1-216-864-11 SHORT CHIP 0
R758 1-216-864-11 SHORT CHIP 0
R760 1-216-864-11 SHORT CHIP 0
R762 1-216-837-11 METAL CHIP 22K 5% 1/10W
R763 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R764 1-216-857-11 METAL CHIP 1M 5% 1/10W
R765 1-216-837-11 METAL CHIP 22K 5% 1/10W
R767 1-216-841-11 METAL CHIP 47K 5% 1/10W
R769 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R776 1-216-864-11 SHORT CHIP 0
R777 1-216-864-11 SHORT CHIP 0
R778 1-216-845-11 METAL CHIP 100K 5% 1/10W
R785 1-216-833-11 METAL CHIP 10K 5% 1/10W
R786 1-216-845-11 METAL CHIP 100K 5% 1/10W
R787 1-216-845-11 METAL CHIP 100K 5% 1/10W
R788 1-216-845-11 METAL CHIP 100K 5% 1/10W
R789 1-216-845-11 METAL CHIP 100K 5% 1/10W
R799 1-216-864-11 SHORT CHIP 0
R805 1-216-864-11 SHORT CHIP 0
R901 1-216-801-11 METAL CHIP 22 5% 1/10W
R902 1-216-801-11 METAL CHIP 22 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/10W
R905 1-216-801-11 METAL CHIP 22 5% 1/10W
R906 1-216-801-11 METAL CHIP 22 5% 1/10W
R907 1-216-801-11 METAL CHIP 22 5% 1/10W
R908 1-216-833-11 METAL CHIP 10K 5% 1/10W
R911 1-216-833-11 METAL CHIP 10K 5% 1/10W
R912 1-216-833-11 METAL CHIP 10K 5% 1/10W
R913 1-216-833-11 METAL CHIP 10K 5% 1/10W
R915 1-216-809-11 METAL CHIP 100 5% 1/10W
R916 1-216-821-11 METAL CHIP 1K 5% 1/10W
R917 1-216-821-11 METAL CHIP 1K 5% 1/10W
R918 1-216-801-11 METAL CHIP 22 5% 1/10W
R920 1-216-809-11 METAL CHIP 100 5% 1/10W
R921 1-216-809-11 METAL CHIP 100 5% 1/10W
R922 1-216-801-11 METAL CHIP 22 5% 1/10W
R923 1-216-813-11 METAL CHIP 220 5% 1/10W
R925 1-216-809-11 METAL CHIP 100 5% 1/10W
R926 1-216-809-11 METAL CHIP 100 5% 1/10W
R927 1-216-857-11 METAL CHIP 1M 5% 1/10W
R928 1-216-809-11 METAL CHIP 100 5% 1/10W
R929 1-216-809-11 METAL CHIP 100 5% 1/10W
R930 1-216-809-11 METAL CHIP 100 5% 1/10W
R931 1-216-801-11 METAL CHIP 22 5% 1/10W
R932 1-216-801-11 METAL CHIP 22 5% 1/10W
R933 1-216-801-11 METAL CHIP 22 5% 1/10W
R935 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R936 1-216-809-11 METAL CHIP 100 5% 1/10W
R938 1-216-833-11 METAL CHIP 10K 5% 1/10W
R940 1-216-809-11 METAL CHIP 100 5% 1/10W
R942 1-216-809-11 METAL CHIP 100 5% 1/10W
R943 1-216-809-11 METAL CHIP 100 5% 1/10W
R958 1-216-801-11 METAL CHIP 22 5% 1/10W
R962 1-216-833-11 METAL CHIP 10K 5% 1/10W
R964 1-216-833-11 METAL CHIP 10K 5% 1/10W
R970 1-216-864-11 SHORT CHIP 0
R974 1-216-864-11 SHORT CHIP 0
R975 1-216-833-11 METAL CHIP 10K 5% 1/10W
R978 1-216-833-11 METAL CHIP 10K 5% 1/10W
R984 1-216-833-11 METAL CHIP 10K 5% 1/10W
R988 1-216-864-11 SHORT CHIP 0
R990 1-216-864-11 SHORT CHIP 0
R994 1-216-864-11 SHORT CHIP 0
R995 1-216-864-11 SHORT CHIP 0
R996 1-216-864-11 SHORT CHIP 0
R997 1-216-864-11 SHORT CHIP 0
R998 1-216-864-11 SHORT CHIP 0
R1000 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1001 1-216-864-11 SHORT CHIP 0
R1302 1-216-864-11 SHORT CHIP 0
R9980 1-216-864-11 SHORT CHIP 0
R9981 1-216-864-11 SHORT CHIP 0
R9998 1-216-864-11 SHORT CHIP 0
R9999 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB202 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB203 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB204 1-234-523-21 RES, CHIP NETWORK 0 (3216)
< VIBRATOR >
X901 1-795-375-11 VIBRATOR, CERAMIC (20MHz))
X902 1-795-630-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
A-1063-581-A FRONT AMP BOARD, COMPLETE (TH)
A-4752-542-A FRONT AMP BOARD, COMPLETE
(E3, E15, SP, MY)
A-4752-564-A FRONT AMP BOARD, COMPLETE (EA)
A-4752-583-A FRONT AMP BOARD, COMPLETE (E2)
************************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C503 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C504 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C505 1-126-964-11 ELECT 10uF 20% 50V
C506 1-126-947-11 ELECT 47uF 20% 35V
C507 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C508 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C509 1-126-947-11 ELECT 47uF 20% 35V
C510 1-126-947-11 ELECT 47uF 20% 35V
C511 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-126-967-11 ELECT 47uF 20% 50V
C516 1-126-967-11 ELECT 47uF 20% 50V
C518 1-128-563-11 ELECT 100uF 20% 100V
C522 1-137-749-11 MYLAR 0.1uF 100V
C523 1-137-749-11 MYLAR 0.1uF 100V
C524 1-137-749-11 MYLAR 0.1uF 100V
C525 1-137-749-11 MYLAR 0.1uF 100V
C526 1-136-497-81 FILM 0.1uF 5% 50V
C527 1-136-497-81 FILM 0.1uF 5% 50V
C528 1-128-562-11 ELECT 47uF 20% 100V
C529 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C530 1-128-550-11 ELECT 2200uF 20% 50V
DMB07 FRONT AMP
To Next Page
