HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C531 1-128-550-11 ELECT 2200uF 20% 50V
C534 1-126-953-11 ELECT 2200uF 20% 35V
C535 1-126-953-11 ELECT 2200uF 20% 35V
C537 1-131-992-91 CERAMIC CHIP 100000PF 35V (EA)
C538 1-131-992-91 CERAMIC CHIP 100000PF 35V (EA)
C539 1-131-992-91 CERAMIC CHIP 100000PF 35V (EA)
C540 1-131-992-91 CERAMIC CHIP 100000PF 35V (EA)
C541 1-131-992-91 CERAMIC CHIP 100000PF 35V (EA)
C542 1-131-992-91 CERAMIC CHIP 100000PF 35V (EA)
C557 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C560 1-126-964-11 ELECT 10uF 20% 50V
C850 1-126-964-11 ELECT 10uF 20% 50V
C851 1-104-658-91 ELECT 100uF 20% 10V
C852 1-126-961-11 ELECT 2.2uF 20% 50V
C853 1-126-923-91 ELECT 220uF 20% 10V
C854 1-126-964-11 ELECT 10uF 20% 50V
C855 1-107-721-11 ELECT 4.7uF 20% 100V
C856 1-107-721-11 ELECT 4.7uF 20% 100V
C857 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C858 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C859 1-126-947-11 ELECT 47uF 20% 35V
C860 1-126-963-11 ELECT 4.7uF 20% 50V
C861 1-104-658-91 ELECT 100uF 20% 10V
C862 1-104-658-91 ELECT 100uF 20% 10V
C865 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
CN501 1-784-031-41 CONNECTOR, BOARD TO BOARD 8P
* CN502 1-564-526-11 PLUG, CONNECTOR 11P
CN505 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
* CN506 1-564-518-11 PLUG, CONNECTOR 3P
CN508 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-083-83 DIODE UDZS-TE17-15B
D503 8-719-083-83 DIODE UDZS-TE17-15B
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D850 8-719-069-56 DIODE UDZSTE-176.2B
D851 8-719-978-33 DIODE DTZ-TT11-6.8B
D852 8-719-988-61 DIODE 1SS355TE-17
D853 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 6-706-124-01 IC STK413-420
IC850 6-703-610-01 IC RT8H015C-T112-1
< COIL >
L501 1-420-872-52 COIL, AIR-CORE (EA)
L502 1-420-872-52 COIL, AIR-CORE (EA)
L503 1-420-872-52 COIL, AIR-CORE (EA)
< TRANSISTOR >
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q503 8-729-271-31 TRANSISTOR 2SC2713-G
Q504 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q506 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q507 8-729-216-31 TRANSISTOR 2SA1163-G
Q508 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q509 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q510 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q850 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q851 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q852 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q853 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q854 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q858 8-729-026-68 TRANSISTOR 2SD2525 (TP)
Q859 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q860 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q861 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q868 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q869 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q890 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R503 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-821-11 METAL CHIP 1K 5% 1/10W
R506 1-216-841-11 METAL CHIP 47K 5% 1/10W
R507 1-216-841-11 METAL CHIP 47K 5% 1/10W
R509 1-216-821-11 METAL CHIP 1K 5% 1/10W
R510 1-216-818-11 METAL CHIP 560 5% 1/10W
R511 1-216-815-11 METAL CHIP 330 5% 1/10W
R512 1-216-815-11 METAL CHIP 330 5% 1/10W
R513 1-216-841-11 METAL CHIP 47K 5% 1/10W
R515 1-216-839-11 METAL CHIP 33K 5% 1/10W
R516 1-216-841-11 METAL CHIP 47K 5% 1/10W
R517 1-216-841-11 METAL CHIP 47K 5% 1/10W
R518 1-216-845-11 METAL CHIP 100K 5% 1/10W
R519 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R520 1-245-605-51 FUSIBLE 100 5% 1/4W
0 R521 1-245-605-51 FUSIBLE 100 5% 1/4W
R522 1-216-835-11 METAL CHIP 15K 5% 1/10W
R523 1-216-839-11 METAL CHIP 33K 5% 1/10W
0 R524 1-217-637-00 FUSIBLE 1 5% 1/4W
R525 1-249-677-31 CARBON 1.5K 5% 1/2W
R526 1-249-677-31 CARBON 1.5K 5% 1/2W
R527 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R529 1-220-755-11 METAL 0.22 10% 2W
R530 1-216-821-11 METAL CHIP 1K 5% 1/10W
R531 1-216-835-11 METAL CHIP 15K 5% 1/10W
R532 1-216-845-11 METAL CHIP 100K 5% 1/10W
FRONT AMP
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
To Next Page
