90
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R533 1-216-845-11 METAL CHIP 100K 5% 1/10W
R534 1-216-835-11 METAL CHIP 15K 5% 1/10W
R535 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R536 1-220-755-11 METAL 0.22 10% 2W
R538 1-216-835-11 METAL CHIP 15K 5% 1/10W
R539 1-216-821-11 METAL CHIP 1K 5% 1/10W
R540 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R541 1-220-894-11 METAL 0.22 10% 5W
R542 1-249-625-31 CARBON 10 5% 1/2W
R543 1-249-625-31 CARBON 10 5% 1/2W
R544 1-249-625-31 CARBON 10 5% 1/2W
R545 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R546 1-216-841-11 METAL CHIP 47K 5% 1/10W
R547 1-216-843-11 METAL CHIP 68K 5% 1/10W
R548 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R549 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R550 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R554 1-216-837-11 METAL CHIP 22K 5% 1/10W
R555 1-216-837-11 METAL CHIP 22K 5% 1/10W
R556 1-216-837-11 METAL CHIP 22K 5% 1/10W
R557 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R559 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R560 1-216-833-11 METAL CHIP 10K 5% 1/10W
R561 1-249-625-31 CARBON 10 5% 1/2W
(EA)
R562 1-249-625-31 CARBON 10 5% 1/2W
(EA)
R563 1-249-625-31 CARBON 10 5% 1/2W
(EA)
R564 1-216-841-11 METAL CHIP 47K 5% 1/10W
R565 1-216-841-11 METAL CHIP 47K 5% 1/10W
R566 1-249-625-31 CARBON 10 5% 1/2W
(EA)
R567 1-216-843-11 METAL CHIP 68K 5% 1/10W
R568 1-216-843-11 METAL CHIP 68K 5% 1/10W
R569 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R570 1-216-458-11 METAL OXIDE 1.8K 5% 2W
0 R571 1-216-458-11 METAL OXIDE 1.8K 5% 2W
0 R572 1-216-458-11 METAL OXIDE 1.8K 5% 2W
0 R573 1-216-458-11 METAL OXIDE 1.8K 5% 2W
R574 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R575 1-216-833-11 METAL CHIP 10K 5% 1/10W
R576 1-249-625-31 CARBON 10 5% 1/2W
(EA)
R577 1-216-841-11 METAL CHIP 47K 5% 1/10W
R578 1-249-625-31 CARBON 10 5% 1/2W
(EA)
0 R580 1-215-863-11 METAL OXIDE 100 5% 1W
0 R581 1-215-863-11 METAL OXIDE 100 5% 1W
R595 1-249-689-31 CARBON 4.7K 5% 1/2W
R596 1-249-689-31 CARBON 4.7K 5% 1/2W
R598 1-249-689-31 CARBON 4.7K 5% 1/2W
R599 1-249-689-31 CARBON 4.7K 5% 1/2W
R850 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R851 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R854 1-216-821-11 METAL CHIP 1K 5% 1/10W
R855 1-215-891-11 METAL OXIDE 680 5% 2W
R857 1-216-821-11 METAL CHIP 1K 5% 1/10W
R858 1-215-891-11 METAL OXIDE 680 5% 2W
R860 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R862 1-216-837-11 METAL CHIP 22K 5% 1/10W
R863 1-216-837-11 METAL CHIP 22K 5% 1/10W
R864 1-216-849-11 METAL CHIP 220K 5% 1/10W
R865 1-216-809-11 METAL CHIP 100 5% 1/10W
R866 1-216-841-11 METAL CHIP 47K 5% 1/10W
R867 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R870 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R871 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R872 1-216-845-11 METAL CHIP 100K 5% 1/10W
R875 1-216-813-11 METAL CHIP 220 5% 1/10W
R876 1-216-813-11 METAL CHIP 220 5% 1/10W
R880 1-216-837-11 METAL CHIP 22K 5% 1/10W
R890 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
RY501 1-755-373-11 RELAY
RY502 1-755-373-11 RELAY
< THERMISTOR >
TH531 1-807-796-11 THERMISTOR
< TERMINAL >
TM502 1-694-656-21 TERMINAL BOARD (6CH SPEAKER) (SPEAKER)
************************************************************
HP BOARD
********
< CAPACITOR >
C1060 1-124-464-11 ELECT 0.22uF 20% 50V
C1061 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1062 1-124-464-11 ELECT 0.22uF 20% 50V
C1063 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1064 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1066 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1067 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C1068 1-124-464-11 ELECT 0.22uF 20% 50V
C1069 1-124-257-00 ELECT 2.2uF 20% 50V
C1070 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C1071 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1072 1-124-247-91 ELECT 10uF 20% 35V
C1073 1-124-257-00 ELECT 2.2uF 20% 50V
C1074 1-126-176-11 ELECT 220uF 20% 10V
C1076 1-124-247-91 ELECT 10uF 20% 35V
C1077 1-126-160-11 ELECT 1uF 20% 50V
C1078 1-124-257-00 ELECT 2.2uF 20% 50V
C1079 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1080 1-126-160-11 ELECT 1uF 20% 50V
C1082 1-124-589-11 ELECT 47uF 20% 16V
C1083 1-124-589-11 ELECT 47uF 20% 16V
C1084 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C1085 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C1086 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1087 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1088 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
FRONT AMP HP
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
To Next Page
