103
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
AMP BD (MD)
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-247-807-31 CARBON 100 5% 1/4W
R813 1-249-417-11 CARBON 1K 5% 1/4W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R817 1-247-903-00 CARBON 1M 5% 1/4W
R818 1-249-429-11 CARBON 10K 5% 1/4W
R819 1-249-431-11 CARBON 15K 5% 1/4W
R820 1-249-431-11 CARBON 15K 5% 1/4W
R821 1-249-437-11 CARBON 47K 5% 1/4W
R822 1-249-438-11 CARBON 56K 5% 1/4W
R824 1-249-438-11 CARBON 56K 5% 1/4W
0R825 1-216-455-81 METAL OXIDE 560 5% 2W F
R826 1-260-076-11 CARBON 10 5% 1/2W
0R827 1-216-455-81 METAL OXIDE 560 5% 2W F
R828 1-260-076-11 CARBON 10 5% 1/2W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R841 1-249-421-11 CARBON 2.2K 5% 1/4W
R842 1-249-421-11 CARBON 2.2K 5% 1/4W
R843 1-247-883-00 CARBON 150K 5% 1/4W
R844 1-249-437-11 CARBON 47K 5% 1/4W
R845 1-249-433-11 CARBON 22K 5% 1/4W
R851 1-260-096-11 CARBON 560 5% 1/2W
R852 1-249-421-11 CARBON 2.2K 5% 1/4W
R853 1-249-433-11 CARBON 22K 5% 1/4W
R854 1-260-096-11 CARBON 560 5% 1/2W
R855 1-247-887-00 CARBON 220K 5% 1/4W
R856 1-249-433-11 CARBON 22K 5% 1/4W
R857 1-249-437-11 CARBON 47K 5% 1/4W
R858 1-247-887-00 CARBON 220K 5% 1/4W
R859 1-249-425-11 CARBON 4.7K 5% 1/4W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-247-887-00 CARBON 220K 5% 1/4W
R863 1-249-417-11 CARBON 1K 5% 1/4W
R864 1-249-437-11 CARBON 47K 5% 1/4W
R871 1-249-431-11 CARBON 15K 5% 1/4W
R872 1-249-431-11 CARBON 15K 5% 1/4W
R876 1-260-076-11 CARBON 10 5% 1/2W
R878 1-260-076-11 CARBON 10 5% 1/2W
< RELAY >
RY801 1-755-170-11 RELAY (12V)
< TERMINAL >
TM801 TERMINAL BOARD (4P) (SPEAKER
IMPEDANCE USE 6-16Ω) (KR)
TM801 1-694-750-11 TERMINAL BOARD (4P) (SPEAKER
IMPEDANCE USE 6-16Ω) (EXCEPT KR)
< THERMISTOR >
TPH851 1-801-829-11 THERMISTOR, POSITIVE
**************************************************************
A-4725-056-A BD (MD) BOARD, COMPLETE
************************
< CAPACITOR >
C101 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C102 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C105 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C109 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C110 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C111 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C112 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C113 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C114 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C115 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C116 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C118 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C119 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C125 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C128 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C131 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C133 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C141 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C142 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C143 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C144 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C145 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C146 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C147 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C151 1-117-370-11 CERAMIC CHIP 10uF 10V
C152 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C153 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C154 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C155 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C157 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C158 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C159 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C160 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C163 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C164 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C165 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C166 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C167 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C169 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C173 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C174 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C180 1-117-370-11 CERAMIC CHIP 10uF 10V
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
