102
SECTION 8
ELECTRICAL PARTS LIST
AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
• Abbreviation
HK : Hong Kong model
JE : Tourist model
KR : Korean model
When indicating parts by reference
number, please include the board.
AMP BOARD
***********
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C804 1-126-965-11 ELECT 22uF 20% 35V
C805 1-126-964-11 ELECT 10uF 20% 50V
C807 1-137-503-11 MYLAR 100PF 5% 50V
C808 1-104-664-11 ELECT 47uF 20% 10V
C810 1-130-495-00 MYLAR 0.1uF 5% 50V
C811 1-130-495-00 MYLAR 0.1uF 5% 50V
C813 1-126-959-11 ELECT 0.47uF 20% 50V
C814 1-126-042-11 ELECT 3300uF 20% 35V
C815 1-126-042-11 ELECT 3300uF 20% 35V
C816 1-104-665-11 ELECT 100uF 20% 25V
C818 1-130-495-00 MYLAR 0.1uF 5% 50V
C819 1-130-495-00 MYLAR 0.1uF 5% 50V
C820 1-130-495-00 MYLAR 0.1uF 5% 50V
C821 1-130-495-00 MYLAR 0.1uF 5% 50V
C822 1-107-715-11 ELECT 22uF 20% 16V
C826 1-137-362-11 PETP FILM 470PF 5% 50V
C851 1-126-949-11 ELECT 220uF 20% 35V
C852 1-126-961-11 ELECT 2.2uF 20% 50V
C853 1-104-665-11 ELECT 100uF 20% 10V
C854 1-126-965-11 ELECT 22uF 20% 35V
C855 1-113-342-11 CERAMIC 0.1uF 50V
C857 1-137-503-11 MYLAR 100PF 5% 50V
C858 1-104-664-11 ELECT 47uF 20% 10V
C859 1-113-342-11 CERAMIC 0.1uF 50V
C870 1-130-495-00 MYLAR 0.1uF 5% 50V
C871 1-130-495-00 MYLAR 0.1uF 5% 50V
C876 1-137-362-11 PETP FILM 470PF 5% 50V
< CONNECTOR >
* CN801 1-564-509-21 PLUG, CONNECTOR 6P
* CN802 1-564-518-11 PLUG, CONNECTOR 3P
* CN803 1-564-510-11 PLUG, CONNECTOR 7P
CN806 1-766-921-11 CONNECTOR, BOARD TO BOARD 10P
* CN851 1-564-517-11 PLUG, CONNECTOR 2P
CN852 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D802 8-719-200-82 DIODE 11ES2-TA2B
D803 8-719-028-23 DIODE D3SBA20-4101
D851 8-719-200-82 DIODE 11ES2-TA2B
D852 8-719-050-84 DIODE RB441Q-40T-72
D853 8-719-911-19 DIODE 1SS133T-72
D854 8-719-921-63 DIODE MTZJ-7.5B
D855 8-719-947-24 DIODE MTZJ-T-72-6.2A
< FUSE >
0F801 1-532-504-31 FUSE (T4AL/250V)
0F802 1-532-504-31 FUSE (T4AL/250V)
< IC >
IC801 8-759-333-24 IC LM1876TF
< COIL >
L801 1-420-872-00 COIL, AIR-CORE
L851 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q802 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q803 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q804 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q805 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q806 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q851 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q852 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q853 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q854 8-729-026-68 TRANSISTOR 2SD2525 (TP)
< RESISTOR >
R801 1-260-096-11 CARBON 560 5% 1/2W
R802 1-249-421-11 CARBON 2.2K 5% 1/4W
R803 1-249-417-11 CARBON 1K 5% 1/4W
R804 1-260-096-11 CARBON 560 5% 1/2W
R805 1-249-441-11 CARBON 100K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
R807 1-249-437-11 CARBON 47K 5% 1/4W
R810 1-249-437-11 CARBON 47K 5% 1/4W
