6-5. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
(In addition to this, the necessary note is printed in each block)
C
B
These are omitted.
E
Q
B
These are omitted.
CE
Q
Note on Printed Wiring Board:
• X : parts extracted from the component side.
• Y : parts extracted from the conductor side.
• b : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
Caution:
Pattern face side: Parts on the pattern face side seen from
(Conductor Side) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(Component Side) the parts face are indicated.
• Indication of transistor.
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
• % : indicates tolerance.
•
f
: internal component.
• 2 : nonflammable resistor.
• 5 : fusible resistor.
• C : panel designation.
• U : B+ Line.
• V : B– Line.
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F : TUNER
J : CD PLAY
E : MD PLAY
j : MD REC
q : DIGITAL OPTICAL IN
d : TAPE IN (PLAY)
G : TAPE OUT (REC)
N : ANALOG IN
• Abbreviation
HK : Hong Kong model
JE : Tourist model
KR : Korean model
Printed wiring board of BD (CD) board is shown only for
referring, because CD base unit is replaced as a block.
• Circuit Boards Location
Schematic diagram of BD (CD) board is shown only for
referring, because CD base unit is replaced as a block.
Note: The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
REG board
AMP board
SELECTOR boar
(Tourist model)
MAIN board
JOG board
JACK board
PANEL board
POWER board
MD DIGITAL board
BD (MD) board
DISC SENSOR board
RELAY board
BD (CD) board
IN OUT SW board
MOTOR board
DRIVER board
TRAY SENSOR board
