Sony HCD-PX5 - Printed Wiring Boards - BD (MD) Board

HCD-PX5
6060
05
(PACK OUT)
PLAY
POSITION
REC
POSITION
13
(13)
BD (MD) BOARD
FLEXIBLE BOARD
(COMPONENT SIDE)
CD
MD DIGITAL BOARD
CN1003
MD DIGITAL BOARD
CN1004
05
(LOADING)
S102-2
PROTECT
DETECT
S102-1
REFLECT
RATE
DETECT
BD (MD) BOARD
(CONDUCTOR SIDE)
17
1
(SLED)
D
D
G
G
TEST
PIN
–1
–2
13
(13)
6-12. PRINTED WIRING BOARDS – BD (MD) Board –• See page 53 for Circuit Boards Location.
There are a few cases that the part isn't mounted in model
is printed on diagrams.
• Semiconductor
Location
Ref. No. Location
D101 A-1
Q101 B-1
Q131 C-1
Q132 B-1
Q133 B-1
Q134 C-1
IC181 D-3
IC190 D-1
IC195 D-2
Q121 B-3
Q122 B-3
Q181 D-3
Q182 D-3
Ref. No. LocationRef. No. Location
D181 D-3
D183 D-3
IC101 A-3
IC102 B-3
IC141 C-1
IC151 C-2
IC152 C-3
• Semiconductor Location
(Page 65) (Page 65)
