Sony HCD-PX5 - Printed Wiring Board - AMP Board

HCD-PX5
7070
(KR)
(KR)
6-21. PRINTED WIRING BOARD – AMP Board –• See page 53 for Circuit Boards Location.
D801 D-3
D802 D-8
D803 C-3
D851 B-3
D852 B-3
D853 B-3
D854 B-4
D855 A-4
IC801 E-3
Q802 D-4
Q803 D-4
Q804 D-4
Q805 E-6
Q806 E-5
Q851 B-3
Q852 B-3
Q853 B-4
Q854 B-4
• Semiconductor
Location
Ref. No. Location
There are a few cases that the part isn't mounted in model
is printed on diagrams.
(Page 76)
(Page 68)
(Page 78)
(Page 68)
(Page 68)
