HCD-PX5
6868
R846
C321
C322
(KR)
(KR)
6-20. PRINTED WIRING BOARD – MAIN Board –• See page 53 for Circuit Boards Location.
There are a few cases that the part isn't mounted in model
is printed on diagrams.
D513 A-11
D514 E-2
D515 E-2
D516 A-11
D518 E-8
D519 E-2
D521 A-7
D522 A-3
D523 A-10
D524 E-3
D525 C-11
D526 B-11
D551 F-10
D552 F-10
Ref. No. LocationRef. No. Location
D402 A-6
D403 A-6
D452 B-6
D453 B-6
D501 C-9
D503 E-3
D504 E-8
D505 E-2
D506 E-1
D507 E-2
D508 A-7
D509 A-11
D510 E-4
D511 E-5
D512 E-4
• Semiconductor Location
Ref. No. Location Ref. No. Location
IC121 C-11
IC401 A-6
IC501 A-9
IC502 A-8
IC505 E-9
IC506 B-3
IC508 E-3
IC601 E-1
Q158 A-11
Q159 A-10
Q160 A-10
Q301 E-7
Q351 D-7
Q501 E-11
Q502 F-11
Q503 A-7
Q504 A-8
Q511 A-4
Q512 A-4
Q513 F-6
Q521 E-4
Q601 E-1
Q671 F-5
Q672 F-5
Q673 F-5
Q674 F-6
(Page 65)
(Page 72)
(Page 78) (Page 76) (Page 76) (Page 70) (Page 70)
(Page 75)
(Page 72)
(Page 70)
