Pin No. Pin Name I/O Description
94 AC CUT IN
I AC power off detection signal input from the reset signal generator (IC508) Not used (open)
95 RDS DATA I
RDS serial data input from the RDS decoder Not used (open)
96 RDS CLK
I RDS serial data transfer clock signal input from the RDS decoder Not used (open)
97 SELF WRITE IN I
Not used
98 OUT
O Not used
99 CLK I
Not used
100 GEQ CE O
Serial data latch pulse signal output to the M62428AFP (IC505)
