97
C
C
D
D
102
102
102
not supplied
#3
#3
not supplied
not supplied
not supplied
#6
#6
#6
#6
#6
#6
#6
#6
#6
#2
#2
#2
#6
#6
#6
#6
not supplied
(POWER board)
not supplied
(AMP board)
not supplied
(REG board)
not supplied
not supplied
not supplied
not supplied
T901
MDM-7X2A
101
CDM63-21BD53
111
105
104
108
107
106
103
103
102
109
110
(3) CHASSIS SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 4-993-867-01 FOOT (8)
102 4-228-689-01 INSULATOR
103 4-228-643-01 SCREW (+BVTTWH M3), STEP
104 1-757-548-11 WIRE (FLAT TYPE) (31 CORE)
105 1-757-086-11 WIRE (FLAT TYPE) (21 CORE)
106 1-757-084-11 WIRE (FLAT TYPE) (27 CORE)
107 1-757-085-11 WIRE (FLAT TYPE) (17 CORE)
108 A-4476-153-A MD DIGITAL BOARD, COMPLETE
109 3-703-244-00 BUSHING (FBS001), CORD
0110 1-575-651-21 CORD, POWER (HK, JE)
0110 1-769-079-11 CORD, POWER (KR)
111 4-231-113-01 SCREW (1.7X3), BTN
0T901 1-435-937-11 TRANSFORMER, POWER (HK, KR)
0T901 1-435-938-11 TRANSFORMER, POWER (JE)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
