– 98 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R107 1-216-088-00 METAL CHIP 43K 5% 1/10W
R108 1-216-088-00 METAL CHIP 43K 5% 1/10W
R109 1-216-093-00 METAL CHIP 68K 5% 1/10W
R114 1-216-101-00 METAL CHIP 150K 5% 1/10W
R115 1-216-101-00 METAL CHIP 150K 5% 1/10W
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R118 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R119 1-216-085-00 METAL CHIP 33K 5% 1/10W
R120 1-216-089-91 RES, CHIP 47K 5% 1/10W
R121 1-216-114-00 RES, CHIP 510K 5% 1/10W
R122 1-216-097-91 RES, CHIP 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R127 1-216-089-91 RES, CHIP 47K 5% 1/10W
R128 1-216-098-00 METAL CHIP 110K 5% 1/10W
R129 1-216-025-91 RES, CHIP 100 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-025-91 RES, CHIP 100 5% 1/10W
R156 1-216-081-00 METAL CHIP 22K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
R159 1-216-121-91 RES, CHIP 1M 5% 1/10W
R161 1-216-097-91 RES, CHIP 100K 5% 1/10W
R162 1-216-073-00 METAL CHIP 10K 5% 1/10W
R163 1-216-121-91 RES, CHIP 1M 5% 1/10W
R164 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R165 1-216-049-91 RES, CHIP 1K 5% 1/10W
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
R167 1-216-081-00 METAL CHIP 22K 5% 1/10W
R168 1-216-073-00 METAL CHIP 10K 5% 1/10W
R169 1-216-079-00 METAL CHIP 18K 5% 1/10W
R170 1-216-081-00 METAL CHIP 22K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-079-00 METAL CHIP 18K 5% 1/10W
R173 1-216-025-91 RES, CHIP 100 5% 1/10W
R174 1-216-033-00 METAL CHIP 220 5% 1/10W
R175 1-216-025-91 RES, CHIP 100 5% 1/10W
R176 1-216-025-91 RES, CHIP 100 5% 1/10W
R177 1-216-025-91 RES, CHIP 100 5% 1/10W
R178 1-216-025-91 RES, CHIP 100 5% 1/10W
R179 1-216-025-91 RES, CHIP 100 5% 1/10W
R180 1-216-025-91 RES, CHIP 100 5% 1/10W
R181 1-216-025-91 RES, CHIP 100 5% 1/10W
R188 1-216-037-00 METAL CHIP 330 5% 1/10W
R190 1-216-097-91 RES, CHIP 100K 5% 1/10W
R191 1-216-105-91 RES, CHIP 220K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-668-206-11 CD-SW BOARD
************
< DIODE >
D631 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D632 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D633 8-719-056-13 LED SML79423C-TP15 (DISC 3)
< TRANSISTOR >
Q613 8-729-029-68 TRANSISTOR DTC114TSA
Q614 8-729-029-68 TRANSISTOR DTC114TSA
Q615 8-729-029-68 TRANSISTOR DTC114TSA
< RESISTOR >
R656 1-249-418-11 CARBON 1.2K 5% 1/4W
R657 1-249-419-11 CARBON 1.5K 5% 1/4W
R658 1-249-421-11 CARBON 2.2K 5% 1/4W
R659 1-247-843-11 CARBON 3.3K 5% 1/4W
R660 1-249-425-11 CARBON 4.7K 5% 1/4W
R691 1-247-804-11 CARBON 75 5% 1/4W
R692 1-247-804-11 CARBON 75 5% 1/4W
R693 1-247-804-11 CARBON 75 5% 1/4W
R694 1-247-804-11 CARBON 75 5% 1/4W
R695 1-247-804-11 CARBON 75 5% 1/4W
R696 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S637 1-771-410-11 SWITCH, KEYBOARD (I/u (POWER))
S638 1-771-410-11 SWITCH, KEYBOARD (DISC 1)
S639 1-771-410-11 SWITCH, KEYBOARD (DISC 2)
S640 1-771-410-11 SWITCH, KEYBOARD (DISC 3)
S641 1-771-410-11 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S642 1-771-410-11 SWITCH, KEYBOARD (6)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
BD CD-SW CONNECTOR
