Sony HCD-RX77 - Disassembly Procedure; Case Disassembly; Front Panel Section Disassembly

– 8 –
CASE
FRONT PANEL SECTION
Note: Follow the disassembly procedure in the numerical order given.
SECTION 3
DISASSEMBLY
1 three screws
(BVTP3 × 8)
2 screw
(CASE3 TP2) (3 × 12)
3 two screws
(CASE3 TP2) (3 × 8)
6 case
2 screw
(CASE3 TP2) (3 × 12)
3 two screws
(CASE3 TP2) (3 × 8
)
4
4
5
3 two claws
4 loading panel
1 Turn the cam to the direction
of arrow
A .
A
9
screw
(BVTP3
× 10)
2 Pull-out the
disc tray.
0 three screws
(BVTT3
× 6)
8 connector
(CN109)
9 screw
(BVTP3
× 10)
6 wire (flat type) (13 core)
(23 cm) (CN201)
7 wire (flat type)
(17 core) (CN107)
5 wire (flat type)
(15 core) (33 cm)
(CN106)
