Sony HCD-RX77 - Electrical Parts List (Power Amp Components)

– 108 –
Ref. No. Part No. Description Remark
C841 1-130-777-00 FILM 0.1uF 10% 100V
(GRX7/GRX7J/RX77: CND)
C841 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK, G, EE, CIS)
C842 1-117-750-11 ELECT 3300uF 20% 63V
(CND)
C842 1-126-974-11 ELECT 3300uF 20% 50V
(AEP, UK, G, EE, CIS)
C842 1-128-493-11 ELECT 4700uF 20% 71V
(GRX7/GRX7J)
C843 1-126-925-11 ELECT 470uF 20% 10V
(AEP, UK, G, EE, CIS)
C843 1-126-934-11 ELECT 220uF 20% 10V
(GRX7/GRX7J/RX77: CND)
C851 1-126-963-11 ELECT 4.7uF 20% 50V
(EXCEPT CND)
C851 1-128-582-11 ELECT 10uF 20% 100V
(CND)
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-126-965-11 ELECT 22uF 20% 50V
(AEP, UK, G, EE, CIS)
C857 1-128-560-11 ELECT 22uF 20% 100V
(GRX7/GRX7J/RX77: CND)
C861 1-136-495-11 FILM 0.068uF 5% 50V
C862 1-136-495-11 FILM 0.068uF 5% 50V
C891 1-130-777-00 FILM 0.1uF 10% 100V
(GRX7/GRX7J/RX77: CND)
C891 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK, G, EE, CIS)
C892 1-117-750-11 ELECT 3300uF 20% 63V
(CND)
C892 1-126-974-11 ELECT 3300uF 20% 50V
(AEP, UK, G, EE, CIS)
C892 1-128-493-11 ELECT 4700uF 20% 71V
(GRX7/GRX7J)
< CONNECTOR >
CN801 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D800 8-719-302-38 DIODE RBV-602-01 (GRX7/GRX7J)
D800 8-719-510-68 DIODE D5SBA20F01 (R700/RX77/RX77S)
D801 8-719-911-19 DIODE 1SS119
D841 8-719-911-19 DIODE 1SS119
D842 8-719-911-19 DIODE 1SS119
D843 8-719-911-19 DIODE 1SS119
D851 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-749-900-34 IC STK-4182MK2 (AEP, UK, G, EE, CIS)
IC801 8-749-921-04 IC STK-4211MK2 (CND)
IC801 8-749-921-68 IC STK-4231MK2 (GRX7/GRX7J)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-029-86 TRANSISTOR DTC124ESA
(GRX7/GRX7J/RX77: CND)
Q832 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
(GRX7/GRX7J/RX77: CND)
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-247-826-00 CARBON 620 5% 1/4W
(AEP, UK, G, EE, CIS)
R803 1-249-412-11 CARBON 390 5% 1/4W
(GRX7/GRX7J/RX77: CND)
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-260-105-11 CARBON 3.3K 5% 1/2W
(AEP, UK, G, EE, CIS)
R805 1-260-107-11 CARBON 4.7K 5% 1/2W
(GRX7/GRX7J/RX77: CND)
R806 1-260-105-11 CARBON 3.3K 5% 1/2W
(AEP, UK, G, EE, CIS)
R806 1-260-107-11 CARBON 4.7K 5% 1/2W
(GRX7/GRX7J/RX77: CND)
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-220-755-11 METAL 0.22 10% 2W F
(AEP, UK, G, EE, CIS)
! R808 1-220-893-11 METAL 0.22 10% 5W F
(GRX7/GRX7J/RX77: CND)
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-099-11 CARBON 1K 5% 1/2W
(AEP, UK, G, EE, CIS)
R814 1-260-103-11 CARBON 2.2K 5% 1/2W
(CND)
R814 1-260-105-11 CARBON 3.3K 5% 1/2W
(GRX7/GRX7J)
R816 1-260-099-11 CARBON 1K 5% 1/2W
(AEP, UK, G, EE, CIS)
R816 1-260-103-11 CARBON 2.2K 5% 1/2W
(CND)
R816 1-260-105-11 CARBON 3.3K 5% 1/2W
(GRX7/GRX7J)
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R831 1-249-441-11 CARBON 100K 5% 1/4W
(GRX7/GRX7J/RX77: CND)
R832 1-249-441-11 CARBON 100K 5% 1/4W
(GRX7/GRX7J/RX77: CND)
R833 1-247-881-00 CARBON 120K 5% 1/4W
(GRX7/GRX7J)
R833 1-249-441-11 CARBON 100K 5% 1/4W
(CND)
R841 1-249-421-11 CARBON 2.2K 5% 1/4W
(AEP, UK, G, EE, CIS)
R841 1-249-428-11 CARBON 8.2K 5% 1/4W
(GRX7/GRX7J/RX77: CND)
R842 1-249-425-11 CARBON 4.7K 5% 1/4W
(AEP, UK, G, EE, CIS)
R842 1-249-429-11 CARBON 10K 5% 1/4W
(GRX7/GRX7J/RX77: CND)
R843 1-247-882-11 CARBON 130K 5% 1/4W
(AEP, UK, G, EE, CIS)
R843 1-247-895-00 CARBON 470K 5% 1/4W
(GRX7/GRX7J/RX77: CND)
Ref. No. Part No. Description Remark
POWER AMP
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
