– 113 –
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R22 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R23 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R24 1-216-025-91 METAL CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-91 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W
R33 1-249-425-11 CARBON 4.7K 5% 1/4W
R34 1-249-425-11 CARBON 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-91 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R41 1-216-013-00 METAL CHIP 33 5% 1/10W
R42 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R43 1-216-037-00 METAL CHIP 330 5% 1/10W
R44 1-216-001-00 METAL CHIP 10 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W
R46 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R47 1-216-097-91 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W
R49 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R52 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R53 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R54 1-216-073-00 METAL CHIP 10K 5% 1/10W
R55 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R57 1-216-162-00 METAL CHIP 33 5% 1/8W
R58 1-216-013-00 METAL CHIP 33 5% 1/10W
R91 1-216-295-91 METAL CHIP 0 5% 1/10W
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1751 1-247-807-31 CARBON 100 5% 1/4W
R1752 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1753 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1754 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1755 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1756 1-249-401-11 CARBON 47 5% 1/4W
R1757 1-216-295-91 METAL CHIP 0 5% 1/10W
< VARIABLE RESISTOR >
RV41 1-238-600-11 RES, ADJ, CARBON 10K
RV42 1-238-600-11 RES, ADJ, CARBON 10K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-767-825-21 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450kHz)
X1751 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
************************************************************
* 1-668-208-11 TRANSFORMER BOARD
*******************
1-533-217-31 HOLDER, FUSE
< CONNECTOR >
CN11 1-564-523-11 PLUG, CONNECTOR 8P
* CN12 1-564-518-11 PLUG, CONNECTOR 3P
CN13 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F11 1-532-388-31 FUSE (T2AL/250V)
(EXCEPT CND, AEP, UK, G, EE, CIS, MX)
! F11 1-532-503-31 FUSE (T1.6AL/250V) (AEP, UK, G, EE, CIS)
! F12 1-532-504-31 FUSE (T4AL/250V) (E2, E3, EA3, MY, SP,
IA, HK, TW, SAF, MX, JE)
! F12 1-533-310-11 FUSE, GLASS TUBE6.3A 125V (CND)
< RESISTOR >
! R11 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX7/GRX7J/RX77: CND)
! R11 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(AEP, UK, G, EE, CIS)
! R12 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX7/GRX7J/RX77: CND)
! R12 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(AEP, UK, G, EE, CIS)
! R13 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX7/GRX7J/RX77: CND)
! R13 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(AEP, UK, G, EE, CIS)
! R14 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX7/GRX7J/RX77: CND)
! R14 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(AEP, UK, G, EE, CIS)
R15 1-202-725-00 SOLID 3.3M 10% 1/2W
(CND)
< SWITCH >
! S11 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(POWER SELECT)
(E2, E3, EA3, MY, SP, IA, HK, TW, SAF)
< TRANSFORMER >
! T11 1-431-659-11 TRANSFORMER, POWER (CND)
! T11 1-431-660-11 TRANSFORMER, POWER (AEP, UK, G, EE, CIS)
! T11 1-431-661-11 TRANSFORMER, POWER (GRX7/GRX7J)
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TCB TRANSFORMER
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
