114
HCD-SR4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C857 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C858 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
< CONNECTOR >
CN810 1-784-859-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< RESISTOR >
R860 1-216-864-11 SHORT CHIP 0
R861 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R866 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R867 1-216-864-11 SHORT CHIP 0
R868 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R874 1-216-833-11 METAL CHIP 10K 5% 1/10W
R875 1-216-837-11 METAL CHIP 22K 5% 1/10W
R876 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S801 1-771-884-31 SWITCH, TACTILE (FUNCTION)
S807 1-771-884-31 SWITCH, TACTILE (GX)
S808 1-771-884-31 SWITCH, TACTILE (.)
S809 1-771-884-31 SWITCH, TACTILE (+ (VOLUME))
S815 1-771-884-31 SWITCH, TACTILE (x)
S816 1-771-884-31 SWITCH, TACTILE (>)
S817 1-771-884-31 SWITCH, TACTILE (- (VOLUME))
S818 1-771-884-31 SWITCH, TACTILE (A)
************************************************************
A-4751-739-A DDCON BOARD, COMPLETE
***********************
< CAPACITOR >
C818 1-124-584-00 ELECT 100uF 20% 10V
C830 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C835 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C836 1-126-795-11 ELECT 10uF 20% 50V
C837 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN800 1-784-213-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN801 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
< DIODE >
D810 8-719-988-61 DIODE 1SS355TE-17
D811 8-719-988-61 DIODE 1SS355TE-17
D813 8-719-988-61 DIODE 1SS355TE-17
D814 8-719-988-61 DIODE 1SS355TE-17
D815 8-719-069-56 DIODE UDZSTE-176.2B
< FERRITE BEAD >
FB001 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB002 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB003 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB806 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB808 1-414-813-11 FERRITE, EMI (SMD) (2012)
< COIL >
L804 1-410-671-31 INDUCTOR 47uH
L805 1-400-135-11 INDUCTOR 1uH
L806 1-400-135-11 INDUCTOR 1uH
L807 1-400-135-11 INDUCTOR 1uH
< TRANSISTOR >
Q802 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R806 1-216-864-11 SHORT CHIP 0
R815 1-216-864-11 SHORT CHIP 0
R839 1-216-839-11 METAL CHIP 33K 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
< TRANSFORMER >
T801 1-443-325-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
DIAT PW BOARD
*************
< CAPACITOR >
C900 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C901 1-128-950-21 ELECT 1000uF 20% 16V
C902 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C904 1-128-950-21 ELECT 1000uF 20% 16V
< CONNECTOR >
CN902 1-564-505-11 PLUG, CONNECTOR 2P
< IC >
IC900 6-700-830-01 IC KIA7809API
************************************************************
DIAT SPK BOARD
**************
< CAPACITOR >
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C341 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-162-294-31 CERAMIC 0.001uF 10% 50V
C343 1-162-294-31 CERAMIC 0.001uF 10% 50V
C344 1-162-294-31 CERAMIC 0.001uF 10% 50V
C345 1-162-294-31 CERAMIC 0.001uF 10% 50V
C481 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C482 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C483 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C484 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C485 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C486 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C487 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C488 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C491 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C492 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C500 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN301 1-564-505-11 PLUG, CONNECTOR 2P
* CN309 1-564-243-11 PIN, CONNECTOR (3.96mm PITCH) 6P
DIAT PWCONTROL KEY DIAT SPKDDCON
