115
HCD-SR4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CN312 1-691-766-21 PLUG (MICRO CONNECTOR) 4P
< GROUND TERMINAL BOARD >
GP307 1-537-770-21 TERMINAL BOARD, GROUND
< JACK >
J301 1-818-634-11 JACK, PIN 1P (WIRELESS SPEAKER)
< TERMINAL >
TB301 1-780-123-11 TERMINAL BOARD (SPEAKER)
************************************************************
A-1056-504-A DIAT TRANSMIT BOARD, COMPLETE (CH)
A-1079-939-A DIAT TRANSMIT BOARD, COMPLETE
(EXCEPT CH)
**************************************
< CAPACITOR >
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C803 1-126-933-11 ELECT 100uF 20% 16V
C805 1-126-933-11 ELECT 100uF 20% 16V
C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C812 1-104-658-91 ELECT 100uF 20% 10V
C813 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C814 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C816 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C819 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C820 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C821 1-104-658-91 ELECT 100uF 20% 10V
C822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C823 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C825 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C826 1-104-658-91 ELECT 100uF 20% 10V
C827 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C829 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C830 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C831 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C832 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C833 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C834 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C835 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C836 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C837 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C838 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C839 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C840 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C841 1-126-961-11 ELECT 2.2uF 20% 50V
C842 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C844 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C845 1-104-658-91 ELECT 100uF 20% 10V
C846 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C847 1-126-933-11 ELECT 100uF 20% 16V
C848 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C849 1-126-933-11 ELECT 100uF 20% 16V
C850 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C860 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C861 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN801 1-784-370-31 CONNECTOR, FFC/FPC 11P
CN802 1-564-505-11 PLUG, CONNECTOR 2P
CN803 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D800 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL BOARD >
EB801 1-537-770-21 TERMINAL BOARD, GROUND
EB802 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB801 1-469-835-21 INDUCTOR, FERRITE BEAD
FB802 1-469-835-21 INDUCTOR, FERRITE BEAD
FB804 1-414-234-22 INDUCTOR, FERRITE BEAD
< IC >
IC801 6-704-261-01 IC TK11225CMCL-G
IC802 8-759-491-47 IC TC74VHCT08AFT (EL)
IC803 8-759-549-01 IC SN74LV125APWR
IC804 8-752-425-05 IC CXD4016R
IC805 8-759-684-21 IC AD8057ART-REEL7
< SHORT >
JR801 1-216-809-11 METAL CHIP 100 5% 1/10W
JR802 1-216-809-11 METAL CHIP 100 5% 1/10W
JR803 1-216-809-11 METAL CHIP 100 5% 1/10W
JR804 1-216-864-11 SHORT CHIP 0
JR805 1-216-864-11 SHORT CHIP 0
JR806 1-216-864-11 SHORT CHIP 0
< COIL >
L801 1-469-525-91 INDUCTOR 10uH
L802 1-469-525-91 INDUCTOR 10uH
L803 1-469-525-91 INDUCTOR 10uH
L804 1-469-525-91 INDUCTOR 10uH
L805 1-469-525-91 INDUCTOR 10uH
L806 1-469-525-91 INDUCTOR 10uH
L807 1-469-525-91 INDUCTOR 10uH
L808 1-469-525-91 INDUCTOR 10uH
L809 1-469-525-91 INDUCTOR 10uH
L810 1-469-525-91 INDUCTOR 10uH
L811 1-400-305-11 INDUCTOR 47uH
L812 1-456-509-11 INDUCTOR 10uH
DIAT SPK DIAT TRANSMIT
