HCD-SR4W
Pin No. Pin Name I/O Description
46 VDDE — Power supply terminal (+3.3V)
47 WMD1 I S-RAM wait mode setting terminal Fixed at “H” in this set
48 VSS — Ground terminal
49 WMD0 I S-RAM wait mode setting terminal Fixed at “H” in this set
50 PAGE2 O Page selection signal output terminal Not used
51 VSS — Ground terminal
52, 53 PAGE1, PAGE0 O Page selection signal output terminal Not used
54 BOOT I Boot mode control signal input terminal Not used
55 BTACT O Boot mode state display signal output terminal Not used
56 BST I Boot strap signal input from the system controller
57 MOD1 I
PLL input frequency selection signal input terminal
“L”: 384fs, “H”: 256fs (fixed at “H” in this set)
58 MOD0 I
Mode setting terminal
“L”: single chip mode, “H”: use prohibition (fixed at “L” in this set)
59 EXLOCK I PLL lock error and data error flag input from the digital audio interface IC
60 VDDI — Power supply terminal (+2.6V)
61 VSS — Ground terminal
62, 63 A17, A16 O Address signal output terminal Not used
64 to 66 A15 to A13 O Address signal output to the S-RAM
67 GP10 O
L/R sampling clock signal (44.1 kHz) output to the D/A converter and stream
processor
68 GP9 O Decode signal output to the system controller
69 GP8 I Bit 1 input terminal of channel status from the digital audio interface IC
70 VDDI — Power supply terminal (+2.6V)
71 VSS — Ground terminal
72 to 75 D15 to D12 I/O Two-way data bus with the S-RAM
76 VDDE — Power supply terminal (+3.3V)
77 to 80 D11 to D8 I/O Two-way data bus with the S-RAM
81 VSS — Ground terminal
82 to 85 A9, A12 to A10 O Address signal output to the S-RAM
86 TDO O Simple emulation data output terminal Not used
87 TMS I Simple emulation data input start/end detection signal input terminal Not used
88 XTRST I Simple emulation asychronous break input terminal Not used
89 TCK I Simple emulation clock signal input terminal Not used
90 TDI I Simple emulation data input terminal Not used
91 VSS — Ground terminal
92 to 97 A8 to A3 O Address signal output to the S-RAM
98, 99 D7, D6 I/O Two-way data bus with the S-RAM
100 VDDI — Power supply terminal (+2.6V)
101 VSS — Ground terminal
102 to 105 D5 to D2 I/O Two-way data bus with the S-RAM
106 VDDE — Power supply terminal (+3.3V)
107, 108 D1, D0 I/O Two-way data bus with the S-RAM
109, 110 A2, A1 O Address signal output to the S-RAM
111 VSS — Ground terminal
112 A0 O Address signal output to the S-RAM
113 PM I PLL reset signal input from the system controller “L”: reset
