DMB08 BOARD IC801 CXD2753R (DSD DECODER)
Pin No. Pin Name I/O Description
1 VSCA0 Ground terminal (for core)
2 XMSLAT I Serial data latch pulse signal input from the mechanism controller
3 MSCK I Serial data transfer clock signal input from the mechanism controller
4 MSDATI I Serial data input from the mechanism controller
5 VDCA0 Power supply terminal (+2.5V) (for core)
6MSDATO O Serial data output to the mechanism controller
7 MSREADY O Ready signal output to the mechanism controller “L”: ready
8 XMSDOE O Serial data output enable signal output terminal Not used
9 XRST I Reset signal input from the mechanism controller “L”: reset
10 SMUTE I
Soft muting on/off control signal input from the mechanism controller
“H”: muting on
11 MCKI I Master clock signal (33.8688 MHz) input
12 VSIOA0 Ground terminal (for I/O)
13 EXCKO1 O Master clock signal (33.8688 MHz) output to the digital audio processor
14 EXCKO2 O External clock 2 signal output terminal Not used
15 LRCK O L/R sampling clock signal (44.1kHz) output terminal Not used
16 F75HZ O Not used
17 VDIOA0 Power supply terminal (+3.3V) (for I/O)
18 to 25 MNT0 to MNT7 O Monitor signal output terminal Not used
26 TCK I Clock signal input from the DVD system processor
27 TDI I Serial data input from the DVD system processor
28 VSCA1 Ground terminal (for core)
29 TDO O Serial data output to the DVD system processor
30 TMS I TMS signal input from the DVD system processor
31 TRST I Reset signal input from the DVD system processor “L”: reset
32 to 34 TEST1 to TEST3 I Input terminal for the test (normally: fixed at “L”)
35 VDCA1 Power supply terminal (+2.5V) (for core)
36 UBIT O Not used
37 XBIT O Not used
38 to 41 SUPDT0 to SUPDT3 O Supplementary data output terminal Not used
42 VSIOA1 Ground terminal (for I/O)
43, 44 SUPDT4, SUPDT5 O Supplementary data output terminal Not used
45 VDIOA1 Power supply terminal (+3.3V) (for I/O)
46, 47 SUPDT6, SUPDT7 O Supplementary data output terminal Not used
48 SUPEN O Supplementary data enable signal output terminal Not used
49 VSCA2 Ground terminal (for core)
50 NC O Not used
51, 52 TEST4, TEST5 I Input terminal for the test (normally: fixed at “L”s)
53 NC O Not used
54 VDCA2 Power supply terminal (+2.5V) (for core)
55, 56 NC O Not used
57 BCKASL I
Input/output selection signal input terminal of bit clock signal (2.8224 MHz) for
DSD data output “L”: input (slave), “H”: output (master) Fixed at “H” in this set
58 VSDSD0 Ground terminal (for DSD data output)
59 BCKAI I Bit clock signal (2.8224 MHz) input terminal for DSD data output Not used
60 BCKAO O Bit clock signal (2.8224 MHz) output terminal for DSD data output
61 PHREFI I Bit clock signal (2.8224 MHz) input terminal for DSD data output Not used
