HCD-TB10
3
four screws
(+BVTT 4
×
6)
6
P-
AMP board
chassis
4
power
transformer
5
three screws
(
+BVTP 2.6
×
8
)
2
screw
(
+BVTP 2.6
×
8
)
1
connector
(CN906)
3-11. Power Trans Former, P-AMP Board
3-12. Cam (CDM55)
6
belt (CDM55)
4
5
8
pulley (LDG)
qs
gear (A)
0
gear (B)
9
roller
2
Push the claw in the
direction of arrow
C
.
qa
cam (CDM55)
3
Pull out the tray.
7
bushing
C
A
B
B
Release
1
Pull out the tray in the arrow direction
A
,
and release the lock while pressing
this claw in the arrow direction
