Sony HCD-TB10 - Motor (Tray) Board Removal; Holder Assy Removal

14
HCD-TB10
3-13. MOTOR (TRAY) Board
1 two screws
(
M 2.6 )
2 MOTOR (TRAY) boar
d
3-14. Holder Assy
2 Remove the Holder (BU) ass
y
in the direction of arrow A .
A
1 floating screw
(PTPWH M2.6)
