Sony HCD-TB10 - Printed Wiring Board - PANEL Section

2929
HCD-TB10
6-9. Printed Wiring Board – PANEL Section –
• See page 19 for Circuit Boards Location.
12
A
B
C
D
E
F
G
34567
IC601
RM601
IC602
PANEL BOARD
TUNER/
BAND
E
1-683-955-
11
(11)
TO
LCD BOARD
CN608
(Page 30)
G
TO
VOL BOARD
CN612
(Page 30)
H
TO
MAIN
BOARD
CN403
(Page 23)
C
TO
CDM BOARD
CN733
(Page 35)
A
Ref. No. Location
D601 D-7
D602 E-7
D603 E-7
D604 F-7
D605 F-7
D606 F-7
D607 F-1
D608 F-2
IC601 E-4
IC602 F-7
Q601 E-7
Q602 C-6
• Semiconductor
Location
