Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
53
HCD-TB10
R634 1-247-843-11 CARBON 3.3K 5% 1/4W
R635 1-249-432-11 CARBON 18K 5% 1/4W
R638 1-249-428-11 CARBON 8.2K 5% 1/4W F
R640 1-249-431-11 CARBON 15K 5% 1/4W
R653 1-249-429-11 CARBON 10K 5% 1/4W
R654 1-249-441-11 CARBON 100K 5% 1/4W
0R655 1-249-421-11 CARBON 2.2K 5% 1/4W F
R656 1-249-421-11 CARBON 2.2K 5% 1/4W F
R657 1-249-429-11 CARBON 10K 5% 1/4W
R661 1-249-421-11 CARBON 2.2K 5% 1/4W F
R662 1-247-843-11 CARBON 3.3K 5% 1/4W
R663 1-249-425-11 CARBON 4.7K 5% 1/4W F
R664 1-249-413-11 CARBON 470 5% 1/4W F
R665 1-249-415-11 CARBON 680 5% 1/4W F
R666 1-249-425-11 CARBON 4.7K 5% 1/4W F
R667 1-249-417-11 CARBON 1K 5% 1/4W F
R668 1-249-419-11 CARBON 1.5K 5% 1/4W F
R669 1-249-427-11 CARBON 6.8K 5% 1/4W F
R670 1-249-419-11 CARBON 1.5K 5% 1/4W F
R671 1-249-419-11 CARBON 1.5K 5% 1/4W F
R672 1-249-417-11 CARBON 1K 5% 1/4W F
R673 1-249-415-11 CARBON 680 5% 1/4W F
R674 1-249-413-11 CARBON 470 5% 1/4W F
R675 1-249-419-11 CARBON 1.5K 5% 1/4W F
R676 1-249-421-11 CARBON 2.2K 5% 1/4W F
R677 1-247-843-11 CARBON 3.3K 5% 1/4W
R678 1-249-417-11 CARBON 1K 5% 1/4W F
R679 1-249-417-11 CARBON 1K 5% 1/4W F
R680 1-249-419-11 CARBON 1.5K 5% 1/4W F
R681 1-249-419-11 CARBON 1.5K 5% 1/4W F
R682 1-249-421-11 CARBON 2.2K 5% 1/4W F
R686 1-249-429-11 CARBON 10K 5% 1/4W
R687 1-249-429-11 CARBON 10K 5% 1/4W
R690 1-249-417-11 CARBON 1K 5% 1/4W F
R695 1-249-437-11 CARBON 47K 5% 1/4W
R696 1-249-435-11 CARBON 33K 5% 1/4W
R901 1-249-429-11 CARBON 10K 5% 1/4W
< VIBRATOR >
RES601 1-579-175-11 VIBRATOR, CERAMIC
< IC >
RM601 8-759-827-70 IC NJL64H400A-1
< RELAY >
RY901 1-755-276-11 RELAY, POWER
< SWITCH >
S601 1-762-196-21 SWITCH, TACT (POWER)
S602 1-762-196-21 SWITCH, TACT (DISPLAY)
S603 1-762-196-21 SWITCH, TACT (DIMMER)
S604 1-762-196-21 SWITCH, TACT (REC)
S605 1-762-196-21 SWITCH, TACT (CD SYNC)
S606 1-762-196-21 SWITCH, TACT (EDIT)
S607 1-762-196-21 SWITCH, TACT (SURROUND)
S608 1-762-196-21 SWITCH, TACT (GROOVE)
S609 1-762-196-21 SWITCH, TACT (EJECT)
S610 1-762-196-21 SWITCH, TACT (FM MODE/REPEAT)
S611 1-762-196-21 SWITCH, TACT (PLAY MODE/TUNING MODE)
S612 1-762-196-21 SWITCH, TACT (ENTER)
S613 1-762-196-21 SWITCH, TACT (FUNCTION)
S614 1-762-196-21 SWITCH, TACT (TREBLE)
S615 1-762-196-21 SWITCH, TACT (BASS)
S616 1-762-196-21 SWITCH, TACT (MUSIC MENU)
S617 1-762-196-21 SWITCH, TACT (STOP)
S618 1-762-196-21 SWITCH, TACT (CD)
S619 1-762-196-21 SWITCH, TACT (TUNER/BAND)
S620 1-762-196-21 SWITCH, TACT (MD)
S621 1-762-196-21 SWITCH, TACT (TAPE)
S622 1-762-196-21 SWITCH, TACT (TUNER MEMORY/DIRECTION)
< VIBRATOR >
X601 1-567-098-41 VIBRATOR, CRYSTAL
**************************************************************
A-4729-709-A P-AMP BOARD, COMPLETE
**********************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20.00% 50V
C502 1-126-964-11 ELECT 10uF 20.00% 50V
C503 1-162-294-31 CERAMIC 0.001uF 10% 50V
C504 1-162-294-31 CERAMIC 0.001uF 10% 50V
C505 1-162-290-31 CERAMIC 470PF 10% 50V
C506 1-162-290-31 CERAMIC 470PF 10% 50V
C507 1-126-964-11 ELECT 10uF 20.00% 50V
C508 1-126-964-11 ELECT 10uF 20.00% 50V
C509 1-126-966-11 ELECT 33uF 20.00% 16V
C510 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C520 1-126-968-11 ELECT 100uF 20.00% 50V
C521 1-162-193-31 CERAMIC 3.3PF 10.00% 50V
C522 1-162-193-31 CERAMIC 3.3PF 10.00% 50V
C523 1-130-493-00 MYLAR 0.068uF 5% 50V
C524 1-130-493-00 MYLAR 0.068uF 5% 50V
C525 1-130-493-00 MYLAR 0.068uF 5% 50V
C526 1-130-493-00 MYLAR 0.068uF 5% 50V
C541 1-136-165-00 FILM 0.1uF 5.00% 50V
C542 1-135-832-11 ELECT 2200uF 20% 50V
C543 1-135-832-11 ELECT 2200uF 20% 50V
C591 1-136-165-00 FILM 0.1uF 5.00% 50V
< CONNECTOR >
CN501 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-028-23 DIODE D3SBA20-4101
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-991-33 DIODE 1SS133T-77
D504 8-719-991-33 DIODE 1SS133T-77
D505 8-719-991-33 DIODE 1SS133T-77
PANEL P-AMP
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
