Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
54
HCD-TB10
< TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
< FUSIBLE >
0FR501 1-202-972-61 FUSIBLE 1 5% 1/4W
0FR502 1-212-881-11 FUSIBLE 100 5% 1/4W
< IC >
IC501 6-600-089-01 IC STK403-070
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q503 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-417-11 CARBON 1K 5% 1/4W F
R503 1-249-438-11 CARBON 56K 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-421-11 CARBON 2.2K 5% 1/4W F
R506 1-249-421-11 CARBON 2.2K 5% 1/4W F
R507 1-249-420-11 CARBON 1.8K 5% 1/4W F
R508 1-249-420-11 CARBON 1.8K 5% 1/4W F
R509 1-249-430-11 CARBON 12K 5% 1/4W
0R510 1-249-435-11 CARBON 33K 5% 1/4W
R511 1-249-429-11 CARBON 10K 5% 1/4W
R512 1-249-438-11 CARBON 56K 5% 1/4W
R513 1-249-438-11 CARBON 56K 5% 1/4W
R514 1-249-417-11 CARBON 1K 5% 1/4W F
R515 1-249-417-11 CARBON 1K 5% 1/4W F
R516 1-249-431-11 CARBON 15K 5% 1/4W
R517 1-249-431-11 CARBON 15K 5% 1/4W
R518 1-249-437-11 CARBON 47K 5% 1/4W
R519 1-249-437-11 CARBON 47K 5% 1/4W
R520 1-260-076-11 CARBON 10 5% 1/2W
R521 1-260-076-11 CARBON 10 5% 1/2W
0R522 1-217-151-00 METAL 0.22 10% 2W
0R523 1-217-151-00 METAL 0.22 10% 2W
R524 1-249-435-11 CARBON 33K 5% 1/4W
R541 1-260-119-11 CARBON 47K 5% 1/2W
R591 1-260-119-11 CARBON 47K 5% 1/2W
**************************************************************
1-683-958-11 POWER TRANSFORMER BOARD
**************************
* 1-533-213-31 HOLDER, FUSE
< CAPACITOR >
C906 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN901 1-564-519-11 PLUG, CONNECTOR 4P
CN906 1-564-521-11 PLUG, CONNECTOR 6P
POWER TRANSFORMER
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
< FUSE >
0F904 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3A/250V
0F905 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3A/250V
0F906 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) T3.15A/250V
0F907 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) T2A/250V
**************************************************************
1-683-957-11 SUB TRANSFORMER BOARD
***********************
1-533-213-31 HOLDER, FUSE (E,TW)
< CAPACITOR >
C901 1-126-933-11 ELECT 100uF 20.00% 16V
C902 1-126-936-11 ELECT 3300uF 20.00% 16V
C903 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
< CONNECTOR >
* CN903 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN905 1-564-321-21 PIN, CONNECTOR(3.96MM PITCH)2P
(AEP,UK,MX,KR)
CN905 1-568-106-11 PIN, CONNECTOR(3.96MM PITCH)4P (E,TW)
CN907 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P
< DIODE >
D901 8-719-200-82 DIODE 11ES2-NTA1B
D902 8-719-200-82 DIODE 11ES2-NTA1B
D903 8-719-200-82 DIODE 11ES2-NTA1B
D904 8-719-200-82 DIODE 11ES2-NTA1B
D905 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0F901 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T4A/250V (E,TW)
< IC >
IC901 8-759-158-62 IC TA78057S
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (E,TW)
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< TRANSFORMER >
0T902 1-435-823-21 TRANSFORMER, POWER (MX)
0T902 1-435-824-21 TRANSFORMER, POWER (AEP,UK)
0T902 1-435-825-21 TRANSFORMER, POWER (E,TW,KR)
**************************************************************
1-683-963-11 VOL BOARD
**********
< CAPACITOR >
C617 1-164-159-21 CERAMIC 0.1uF 50V
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
P-AMP SUB TRANSFORMER VOL
