6-12. Printed Wiring Board – AMP Section –
• See page 19 for Circuit Boards Location.
12
A
B
C
3
IC501
P-AMP BOARD
1-683-956-
11
(11)
14
1
T0
MAIN
BOARD
CN402
(Page 23)
E
T0
POWER
TRANSFORMER
BOARD
CN901
(Page 33)
K
Ref. No. Location
D501 B-1
D502 A-2
D503 A-2
D504 B-2
D505 A-1
IC501 A-3
Q501 B-2
Q502 A-2
Q503 A-2
• Semiconductor
Location
