9
HCD-TB10
3-3. Cassette Mechanism (CMAL1Z222A)
7
cassette mechanism dec
k
(CMAL1Z222A)
6
flat cable (9 core)
1
two
screws
(
+BVTP 2.6
×
8
)
2
two
screws
(
+BVTP 2.6
×
8
)
4
screw
(
+PTPWH 2.6
×
5
)
3
screw
(
+PTPWH 2.6
×
5
)
5
shield tc
(Cassette mechanism)
3-4. Front Panel
5
three
screws
(
+BVTP 3
×
10
)
6
front panel
2
flat cable (30 core)
(CN403)
3
flat cable (15 core)
(CN733)
4
connector
(CN304)
1
s
crew
(
+BVTP 2.6
×
8
)
