Sony HCD-TB10 - Diagrams and Layouts; Circuit Boards Location

19
HCD-TB10
SECTION 6
DIAGRAMS
6-1. Circuit Boards Location
MAIN board
PANEL board
LCD board
BACK LIGHT board
H/P board
VOL board
SUB TRANSFORMER board
P-AMP board
CDM board
POWER TRANSFORMER boar
d
MOTOR (TRAY) board
MOTOR board
