55
HCD-TB10
< RESISTOR >
R682 1-249-421-11 CARBON 2.2K 5% 1/4W F
R683 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S623 1-786-289-11 SWITCH, DETECTION (+/-)
<VARIABLERESISTOR >
VR601 1-473-534-11 ENCODER, ROTARY (VOL)
**************************************************************
MISCELLANEOUS
***************
5 1-796-351-21 MECHANISM, SIGNAL CASSETTE
9 1-575-783-21 WIRE(FLAT TYPE) (9 CORE)
70 1-773-006-11 WIRE(FLAT TYPE) (15 CORE)
0106 1-769-079-21 CORD, POWER (KR)
0106 1-777-071-82 CORD, POWER (AEP,UK,E,TW)
0106 1-791-901-21 CORD, POWER (MX)
501 1-683-960-11 MOTOR (TRAY) BOARD
512 1-452-925-21 MAGNET ASSY
517 1-823-059-11 WIRE (FLAT TYPE) (16 CORE)
0521 8-820-020-02 OPTICAL PICK-UP BLOCK KSM-213DCP
0F901 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T4A/250V (E,TW)
0F904 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3A/250V
0F905 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3A/250V
0F906 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) T3.15A/250V
0F907 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) T2A/250V
M103 A-4672-984-A MOTOR (LD) ASSY
0T901 1-437-619-11 TRANSFORMER, POWER (AEP,UK)
0T901 1-437-721-11 TRANSFORMER, POWER (E,MX,TW,KR)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remarks
