Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
52
HCD-TB10
< ADJ >
SFR101 1-241-765-11 RES, ADJ, CARBON 22K
< SWITCH >
* SW301 1-537-738-21 TERMINAL, EARTH
SW301 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY)
< TRANSFORMER >
T101 1-435-792-11 TRANSFORMER, DISCRIMINATOR
< VIBRATOR >
X101 1-760-549-31 VIBRATOR, CRYSTAL 4.5MHz
X102 1-579-900-21 VIBRATOR, CRYSTAL 4.332Mz (AEP,UK)
**************************************************************
1-684-562-11 MOTOR BOARD
*************
< CONNECTOR >
CN01 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
S01 1-771-821-11 SWITCH, PUSH (1 KEY) (LIMIT SW)
**************************************************************
1-683-960-11 MOTOR(TRAY) BOARD
*******************
S701 1-786-203-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
**************************************************************
A-4729-704-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C601 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C602 1-161-494-00 CERAMIC 0.022uF 25V
C603 1-126-964-11 ELECT 10uF 20.00% 50V
C604 1-161-494-00 CERAMIC 0.022uF 25V
C605 1-126-947-11 ELECT 47uF 20.00% 16V
C606 1-162-294-31 CERAMIC 0.001uF 10% 50V
C607 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C608 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C610 1-164-159-21 CERAMIC 0.1uF 50V
C611 1-164-159-21 CERAMIC 0.1uF 50V
C612 1-136-165-00 FILM 0.1uF 5.00% 50V
C613 1-162-205-31 CERAMIC 18PF 5% 50V
C614 1-162-203-31 CERAMIC 15PF 5.00% 50V
C615 1-128-551-11 ELECT 22uF 20.00% 25V
C616 1-164-159-21 CERAMIC 0.1uF 50V
C618 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C619 1-164-159-21 CERAMIC 0.1uF 50V
C620 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN602 1-784-737-11 CONNECTOR, FFC 15P
CN603 1-784-752-11 CONNECTOR, FFC 30P
CN607 1-784-761-11 CONNECTOR, FFC 39P
* CN611 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
D603 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D605 8-719-991-33 DIODE 1SS133T-77
D606 8-719-991-33 DIODE 1SS133T-77
D607 8-719-991-33 DIODE 1SS133T-77
D608 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
FB605 1-412-473-21 INDUCTOR 0UH
FB606 1-412-473-21 INDUCTOR 0UH
< IC >
IC601 6-801-218-01 IC LC877348A-5Z50E
IC602 8-759-635-63 IC M51943BSL-TP
< LED >
LED601 8-719-058-04 DIODE SEL5223S-TP15 (POWER SAVE)
LED602 8-719-058-04 DIODE SEL5223S-TP15 (REC/PAUSE)
< TRANSISTOR >
Q601 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q602 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-249-441-11 CARBON 100K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-415-11 CARBON 680 5% 1/4W F
R606 1-247-891-00 CARBON 330K 5% 1/4W
R607 1-259-884-11 CARBON 4.7M 5% 1/4W
R609 1-249-431-11 CARBON 15K 5% 1/4W
R610 1-249-431-11 CARBON 15K 5% 1/4W
R611 1-249-413-11 CARBON 470 5% 1/4W F
R612 1-249-415-11 CARBON 680 5% 1/4W F
R613 1-249-429-11 CARBON 10K 5% 1/4W
R614 1-249-429-11 CARBON 10K 5% 1/4W
R615 1-249-440-11 CARBON 82K 5% 1/4W
R616 1-249-436-11 CARBON 39K 5% 1/4W
R617 1-249-425-11 CARBON 4.7K 5% 1/4W F
R618 1-249-437-11 CARBON 47K 5% 1/4W
R619 1-249-428-11 CARBON 8.2K 5% 1/4W F
R620 1-249-428-11 CARBON 8.2K 5% 1/4W F
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-249-437-11 CARBON 47K 5% 1/4W
R623 1-249-417-11 CARBON 1K 5% 1/4W F
R624 1-247-807-31 CARBON 100 5% 1/4W
R625 1-247-807-31 CARBON 100 5% 1/4W
R626 1-249-429-11 CARBON 10K 5% 1/4W
R627 1-249-429-11 CARBON 10K 5% 1/4W
R628 1-249-429-11 CARBON 10K 5% 1/4W
R632 1-249-421-11 CARBON 2.2K 5% 1/4W F
MOTOR (TRAY) PANELMOTORMAIN
