38
HCD-TB10
IC102 LC72131D
PHASE
DETECTOR
CHARGE PUMP
SWALLOW COUNTER
1/16, 1/17 4BITS
12BITS
PROGRAMMABLE
DRIVER
UNIVERSAL
COUNTER
REFERENCE
DIVIDER
POWER
ON
RESET
1/2
CCB
INTERFACE
1
3
4
5
6
7
8
9
10
18
17
16
15
13
12
11
19
20
2122
XOUT
GND AOUT AIN
PD
VDD FMOSC
AMOSC
14
NC
XIN
DO
CL
DI
CE
2
NC
IFIN
SD/IN
FA
VCO STOP
IF REQ
FM
NC
UNLOCK
DETECTOR
DATA SHIFT REGISTER LATCH
IC103 BU1924
1 2 3 4 5 6 7 8
910111213141516
QUAL
RDATA
VREF
VDD1
VSS1
MUX
VSS3
CMP
RCLK XO XI (NC) VDD2 VSS2 T1 T2
8TH SWITCHED
CAPACITOR
FILTER
PLL 57KHz
RDS/ARI
BIPHASE
DECODER
DEFFERENTIAL
DECODER
PLL
1187.5Hz
TEST
CLOCK
IC301 BD3873FS
24
CAP
23
TNF1
22
TNF2
21
BNF2
20
BOUT2
19
BNF1
18
BOUT1
17
OUT1
16
OUT2
15
VCC
14
SI
13
SC
1
VIN1
2
VIN2
3
SEL2
4
SEL1
5
A1
6
A2
7
B1
8
B2
9
C1
10
C2
11
FILTER
12
GND
0dB-
-87dB
-
Vcc/2 Vcc/2
Surround
50k 50k 50k 50k 50k 50k
Vcc/2 Vcc/2
Vcc/2
Treble1
fc=8kHz
Treble2
fc=8kHz
Bass2
fo=80Hz
Bass1
fo=80Hz
Logic
