Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
46
HCD-TB10
C782 1-164-159-21 CERAMIC 0.1uF 50V
C786 1-161-494-00 CERAMIC 0.022uF 25V
C787 1-104-665-11 ELECT 100uF 20.00% 10V
C788 1-162-290-31 CERAMIC 470PF 10% 50V
C789 1-164-159-21 CERAMIC 0.1uF 50V
C790 1-164-159-21 CERAMIC 0.1uF 50V
C791 1-164-159-21 CERAMIC 0.1uF 50V
C792 1-164-159-21 CERAMIC 0.1uF 50V
C794 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN731 1-779-553-11 CONNECTOR,FFC(LIF(NON-ZIF))16P
* CN732 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN733 1-784-776-11 CONNECTOR, FFC 15P
* CN734 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN735 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D731 8-719-991-33 DIODE 1SS133T-77
D732 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB751 1-410-397-21 FERRITE BEAD INDUCTOR
FB752 1-410-397-21 FERRITE BEAD INDUCTOR
FB753 1-410-397-21 FERRITE BEAD INDUCTOR
FB754 1-410-397-21 FERRITE BEAD INDUCTOR
FB755 1-410-397-21 FERRITE BEAD INDUCTOR
FB756 1-410-397-21 FERRITE BEAD INDUCTOR
< IC >
IC731 6-702-016-01 IC LA9242M
IC751 6-700-355-01 IC LC78622NE
IC781 8-759-658-87 IC BA5810FP-E2
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
L702 1-410-509-11 INDUCTOR 10uH
L703 1-410-521-11 INDUCTOR 100uH
L704 1-410-509-11 INDUCTOR 10uH
L705 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q731 8-729-116-57 TRANSISTOR 2SB1068TP-K
Q771 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q772 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q773 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q774 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q775 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-249-393-11 CARBON 10 5% 1/4W F
R705 1-247-807-31 CARBON 100 5% 1/4W
R706 1-247-807-31 CARBON 100 5% 1/4W
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-249-441-11 CARBON 100K 5% 1/4W
R709 1-249-427-11 CARBON 6.8K 5% 1/4W F
R710 1-249-421-11 CARBON 2.2K 5% 1/4W F
R715 1-249-430-11 CARBON 12K 5% 1/4W
R716 1-249-439-11 CARBON 68K 5% 1/4W
R717 1-249-439-11 CARBON 68K 5% 1/4W
R718 1-249-436-11 CARBON 39K 5% 1/4W
R719 1-247-843-11 CARBON 3.3K 5% 1/4W
R720 1-249-434-11 CARBON 27K 5% 1/4W
R721 1-249-414-11 CARBON 560 5% 1/4W F
R722 1-249-433-11 CARBON 22K 5% 1/4W
R724 1-249-433-11 CARBON 22K 5% 1/4W
R725 1-249-430-11 CARBON 12K 5% 1/4W
R727 1-249-427-11 CARBON 6.8K 5% 1/4W F
R728 1-249-435-11 CARBON 33K 5% 1/4W
R729 1-249-419-11 CARBON 1.5K 5% 1/4W F
R731 1-249-432-11 CARBON 18K 5% 1/4W
R732 1-247-885-00 CARBON 180K 5% 1/4W
R733 1-249-438-11 CARBON 56K 5% 1/4W
R734 1-249-434-11 CARBON 27K 5% 1/4W
R735 1-249-435-11 CARBON 33K 5% 1/4W
R736 1-249-419-11 CARBON 1.5K 5% 1/4W F
R737 1-249-417-11 CARBON 1K 5% 1/4W F
R738 1-247-807-31 CARBON 100 5% 1/4W
R739 1-249-419-11 CARBON 1.5K 5% 1/4W F
R740 1-249-427-11 CARBON 6.8K 5% 1/4W F
R741 1-249-424-11 CARBON 3.9K 5% 1/4W F
R742 1-247-897-11 CARBON 560K 5% 1/4W
R743 1-247-897-11 CARBON 560K 5% 1/4W
R744 1-249-428-11 CARBON 8.2K 5% 1/4W F
R745 1-249-431-11 CARBON 15K 5% 1/4W
R746 1-249-411-11 CARBON 330 5% 1/4W
R747 1-249-433-11 CARBON 22K 5% 1/4W
R748 1-249-437-11 CARBON 47K 5% 1/4W
R749 1-249-415-11 CARBON 680 5% 1/4W F
R750 1-249-425-11 CARBON 4.7K 5% 1/4W F
R751 1-249-415-11 CARBON 680 5% 1/4W F
R752 1-249-434-11 CARBON 27K 5% 1/4W
R753 1-249-418-11 CARBON 1.2K 5% 1/4W F
R754 1-249-435-11 CARBON 33K 5% 1/4W
R755 1-249-442-11 CARBON 510 5% 1/4W
R756 1-247-903-00 CARBON 1M 5% 1/4W
R757 1-249-437-11 CARBON 47K 5% 1/4W
R758 1-249-421-11 CARBON 2.2K 5% 1/4W F
R759 1-249-417-11 CARBON 1K 5% 1/4W F
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-249-417-11 CARBON 1K 5% 1/4W F
R762 1-249-417-11 CARBON 1K 5% 1/4W F
R763 1-249-417-11 CARBON 1K 5% 1/4W F
R764 1-249-417-11 CARBON 1K 5% 1/4W F
R765 1-249-417-11 CARBON 1K 5% 1/4W F
R766 1-247-807-31 CARBON 100 5% 1/4W
R771 1-249-429-11 CARBON 10K 5% 1/4W
R772 1-249-429-11 CARBON 10K 5% 1/4W
R773 1-249-429-11 CARBON 10K 5% 1/4W
R774 1-249-429-11 CARBON 10K 5% 1/4W
R775 1-249-429-11 CARBON 10K 5% 1/4W
R776 1-249-429-11 CARBON 10K 5% 1/4W
R777 1-249-421-11 CARBON 2.2K 5% 1/4W F
R778 1-249-421-11 CARBON 2.2K 5% 1/4W F
