Sony HCD-TB10 - Page 50

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
50
HCD-TB10
Q305 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q306 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q309 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q401 8-729-116-02 TRANSISTOR BA1A4M-TP
Q402 8-729-049-79 TRANSISTOR RT1P137S-TP
Q403 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
Q404 8-729-116-02 TRANSISTOR BA1A4M-TP
Q405 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
Q406 8-729-116-02 TRANSISTOR BA1A4M-TP
Q407 8-729-900-63 TRANSISTOR BN1F4M-TP
Q408 8-729-116-02 TRANSISTOR BA1A4M-TP
Q409 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q411 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q412 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q413 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q414 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q415 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q417 8-729-900-63 TRANSISTOR BN1F4M-TP
Q418 8-729-116-02 TRANSISTOR BA1A4M-TP
Q421 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q422 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R8 1-249-425-11 CARBON 4.7K 5% 1/4W F
(AEP,UK)
R101 1-249-407-11 CARBON 150 5% 1/4W F
R102 1-249-415-11 CARBON 680 5% 1/4W F
R103 1-249-415-11 CARBON 680 5% 1/4W F
R104 1-249-411-11 CARBON 330 5% 1/4W
R105 1-249-417-11 CARBON 1K 5% 1/4W F
R106 1-249-401-11 CARBON 47 5% 1/4W F
R107 1-249-401-11 CARBON 47 5% 1/4W F
R108 1-249-404-00 CARBON 82 5% 1/4W F
R109 1-249-429-11 CARBON 10K 5% 1/4W
R111 1-249-434-11 CARBON 27K 5% 1/4W
R112 1-249-433-11 CARBON 22K 5% 1/4W
R113 1-249-425-11 CARBON 4.7K 5% 1/4W F
R114 1-249-431-11 CARBON 15K 5% 1/4W
R115 1-249-429-11 CARBON 10K 5% 1/4W
R116 1-249-441-11 CARBON 100K 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R118 1-249-425-11 CARBON 4.7K 5% 1/4W F
R120 1-247-843-11 CARBON 3.3K 5% 1/4W
R121 1-249-415-11 CARBON 680 5% 1/4W F
R122 1-249-425-11 CARBON 4.7K 5% 1/4W F
R123 1-249-425-11 CARBON 4.7K 5% 1/4W F
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-249-429-11 CARBON 10K 5% 1/4W
R126 1-247-843-11 CARBON 3.3K 5% 1/4W
R127 1-247-843-11 CARBON 3.3K 5% 1/4W
0R128 1-249-425-11 CARBON 4.7K 5% 1/4W F
(E,MX,TW,KR)
R129 1-247-807-31 CARBON 100 5% 1/4W
R130 1-249-425-11 CARBON 4.7K 5% 1/4W F
R131 1-247-807-31 CARBON 100 5% 1/4W
R132 1-249-417-11 CARBON 1K 5% 1/4W F
R133 1-249-417-11 CARBON 1K 5% 1/4W F
R134 1-249-417-11 CARBON 1K 5% 1/4W F
R135 1-247-843-11 CARBON 3.3K 5% 1/4W
R136 1-249-429-11 CARBON 10K 5% 1/4W
R137 1-249-429-11 CARBON 10K 5% 1/4W
R138 1-249-429-11 CARBON 10K 5% 1/4W
R139 1-249-417-11 CARBON 1K 5% 1/4W F
R140 1-249-417-11 CARBON 1K 5% 1/4W F
R141 1-249-439-11 CARBON 68K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
R144 1-247-843-11 CARBON 3.3K 5% 1/4W
R145 1-249-435-11 CARBON 33K 5% 1/4W
R149 1-249-437-11 CARBON 47K 5% 1/4W
R150 1-249-437-11 CARBON 47K 5% 1/4W
R151 1-249-429-11 CARBON 10K 5% 1/4W
R152 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R172 1-249-437-11 CARBON 47K 5% 1/4W
(AEP,UK)
R173 1-249-433-11 CARBON 22K 5% 1/4W
(AEP,UK)
R174 1-249-417-11 CARBON 1K 5% 1/4W F
(AEP,UK)
R175 1-249-413-11 CARBON 470 5% 1/4W F
(AEP,UK)
R177 1-249-401-11 CARBON 47 5% 1/4W F
(AEP,UK)
R181 1-249-425-11 CARBON 4.7K 5% 1/4W F
(AEP,UK)
R183 1-249-409-11 CARBON 220 5% 1/4W F
(AEP,UK)
R203 1-249-428-11 CARBON 8.2K 5% 1/4W F
R204 1-249-428-11 CARBON 8.2K 5% 1/4W F
R205 1-249-425-11 CARBON 4.7K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-249-429-11 CARBON 10K 5% 1/4W
R209 1-249-429-11 CARBON 10K 5% 1/4W
R210 1-249-429-11 CARBON 10K 5% 1/4W
R211 1-249-425-11 CARBON 4.7K 5% 1/4W F
R212 1-249-425-11 CARBON 4.7K 5% 1/4W F
R213 1-249-420-11 CARBON 1.8K 5% 1/4W F
0R214 1-249-420-11 CARBON 1.8K 5% 1/4W F
R217 1-249-421-11 CARBON 2.2K 5% 1/4W F
R218 1-249-421-11 CARBON 2.2K 5% 1/4W F
R219 1-249-435-11 CARBON 33K 5% 1/4W
R220 1-249-435-11 CARBON 33K 5% 1/4W
R221 1-249-425-11 CARBON 4.7K 5% 1/4W F
R222 1-249-429-11 CARBON 10K 5% 1/4W
R223 1-249-429-11 CARBON 10K 5% 1/4W
R225 1-249-429-11 CARBON 10K 5% 1/4W
R226 1-249-429-11 CARBON 10K 5% 1/4W
R227 1-249-428-11 CARBON 8.2K 5% 1/4W F
R228 1-249-428-11 CARBON 8.2K 5% 1/4W F
R229 1-249-433-11 CARBON 22K 5% 1/4W
R230 1-247-903-00 CARBON 1M 5% 1/4W
MAIN
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
