Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
79
R175 1-216-025-91 RES,CHIP 100 5% 1/10W
R203 1-216-025-91 RES,CHIP 100 5% 1/10W
R204 1-216-025-91 RES,CHIP 100 5% 1/10W
R205 1-216-025-91 RES,CHIP 100 5% 1/10W
R206 1-216-295-91 SHORT 0
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* A-4673-765-A CD MOTOR BOARD, COMPLETE
*************************
* 4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-124-907-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-124-907-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY) (UP SWITCH)
************************************************************
* 1-672-186-12 CD-L BOARD
**********
< CONNECTOR >
* CN812 1-568-944-11 PIN, CONNECTOR 6P
< DIODE >
D641 8-719-058-04 DIODE SEL5223S-TP15 (NON-STOP)
< RESISTOR >
R731 1-249-410-11 CARBON 270 5% 1/4W F
R732 1-249-411-11 CARBON 330 5% 1/4W
R733 1-249-413-11 CARBON 470 5% 1/4W F
R734 1-249-414-11 CARBON 560 5% 1/4W F
R735 1-249-415-11 CARBON 680 5% 1/4W F
R736 1-249-417-11 CARBON 1K 5% 1/4W F
R737 1-249-418-11 CARBON 1.2K 5% 1/4W F
R738 1-249-420-11 CARBON 1.8K 5% 1/4W F
R739 1-249-422-11 CARBON 2.7K 5% 1/4W F
R740 1-247-843-11 CARBON 3.3K 5% 1/4W
R741 1-249-425-11 CARBON 4.7K 5% 1/4W F
R742 1-249-427-11 CARBON 6.8K 5% 1/4W F
R743 1-249-429-11 CARBON 10K 5% 1/4W
R744 1-249-431-11 CARBON 15K 5% 1/4W
R745 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S660 1-554-303-21 SWITCH, TACTILE (KEY-CON b)
S661 1-554-303-21 SWITCH, TACTILE (DISC 1)
S662 1-554-303-21 SWITCH, TACTILE (DISC 2)
S663 1-554-303-21 SWITCH, TACTILE (DISC 3)
S664 1-554-303-21 SWITCH, TACTILE (DISC 4)
S665 1-554-303-21 SWITCH, TACTILE (DISC 5)
S666 1-554-303-21 SWITCH, TACTILE (FLASH)
S667 1-554-303-21 SWITCH, TACTILE (NEXT)
S668 1-554-303-21 SWITCH, TACTILE (PREV)
S669 1-554-303-21 SWITCH, TACTILE (RETURN)
S670 1-554-303-21 SWITCH, TACTILE (SELECT)
S671 1-554-303-21 SWITCH, TACTILE (ACTIVE)
S672 1-554-303-21 SWITCH, TACTILE (EDIT)
S673 1-554-303-21 SWITCH, TACTILE (NON-STOP)
S674 1-554-303-21 SWITCH, TACTILE (LOOP)
************************************************************
* 1-672-187-12 CD-R BOARD
**********
< CAPACITOR >
C613 1-162-306-11 CERAMIC 0.01uF 30% 16V
C614 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE)7P
< DIODE >
D700 8-719-056-13 DIODE SML79423C-TP15 (PLAY PAUSE)
< RESISTOR >
R751 1-247-843-11 CARBON 3.3K 5% 1/4W
R752 1-249-425-11 CARBON 4.7K 5% 1/4W F
R753 1-249-427-11 CARBON 6.8K 5% 1/4W F
R754 1-249-429-11 CARBON 10K 5% 1/4W
R755 1-249-431-11 CARBON 15K 5% 1/4W
R756 1-249-434-11 CARBON 27K 5% 1/4W
R757 1-249-438-11 CARBON 56K 5% 1/4W
R758 1-247-804-11 CARBON 75 5% 1/4W
R759 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S676 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S677 1-554-303-21 SWITCH, TACTILE (REPEAT)
S678 1-554-303-21 SWITCH, TACTILE (REW)
S679 1-554-303-21 SWITCH, TACTILE (FF)
S681 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S682 1-554-303-21 SWITCH, TACTILE (STOP)
S683 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
S702 1-473-534-11 ENCODER, ROTARY (AMS)
************************************************************
CD MOTOR CD-L CD-RBD
