Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
80
* 1-672-191-12 DOOR-SW BOARD
**************
< CAPACITOR >
C691 1-162-306-11 CERAMIC 0.01uF 30% 16V
< SWITCH >
S691 1-771-057-11 SWITCH, PUSH (1 KEY) (OPEN)
************************************************************
A-4426-364-A FL BOARD, COMPLETE (EA,MY,SP,IA)
******************
A-4426-808-A FL BOARD, COMPLETE (TH)
******************
* 4-214-749-01 HOLDER (925), FL TUBE
* 4-949-935-81 CUSHION (FL)
< CAPACITOR >
C601 1-104-664-11 ELECT 47uF 20% 10V
C602 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-126-960-11 ELECT 1uF 20% 50V
C606 1-126-960-11 ELECT 1uF 20% 50V
C608 1-104-665-11 ELECT 100uF 20% 10V
C609 1-162-294-31 CERAMIC 0.001uF 10% 50V
C610 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C611 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C612 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C613 1-104-664-11 ELECT 47uF 20% 16V
C616 1-162-294-31 CERAMIC 0.001uF 10% 50V
C617 1-162-306-11 CERAMIC 0.01uF 30% 16V
C621 1-126-964-11 ELECT 10uF 20% 50V
C622 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C623 1-126-964-11 ELECT 10uF 20% 50V
C624 1-104-664-11 ELECT 47uF 20% 16V
C625 1-126-963-11 ELECT 4.7uF 20% 50V
C626 1-126-964-11 ELECT 10uF 20% 50V
C641 1-162-286-21 CERAMIC 220PF 10% 50V
C642 1-162-286-21 CERAMIC 220PF 10% 50V
C643 1-162-286-21 CERAMIC 220PF 10% 50V
C644 1-162-286-21 CERAMIC 220PF 10% 50V
C645 1-162-286-21 CERAMIC 220PF 10% 50V
C646 1-162-286-21 CERAMIC 220PF 10% 50V
C647 1-162-286-21 CERAMIC 220PF 10% 50V
C648 1-162-286-21 CERAMIC 220PF 10% 50V
C649 1-162-286-21 CERAMIC 220PF 10% 50V
C650 1-162-286-21 CERAMIC 220PF 10% 50V
C651 1-162-286-21 CERAMIC 220PF 10% 50V
C652 1-162-286-21 CERAMIC 220PF 10% 50V
C653 1-162-286-21 CERAMIC 220PF 10% 50V
C654 1-162-286-21 CERAMIC 220PF 10% 50V
C655 1-162-286-21 CERAMIC 220PF 10% 50V
C656 1-162-286-21 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN601 1-784-776-11 CONNECTOR, FFC 15P
CN602 1-784-737-11 CONNECTOR, FFC 15P
< DIODE >
D601 8-719-071-44 DIODE SELS5223C-TP15 (STAND-BY)
D602 8-719-058-04 DIODE SEL5223S-TP15 (DAILY)
D603 8-719-058-04 DIODE SEL5223S-TP15 (REC)
D604 8-719-058-04 DIODE SEL5223S-TP15 (SYNC EQ)
D605 8-719-058-04 DIODE SEL5223S-TP15 (SYNC BASS)
D606 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D607 8-719-058-04 DIODE SEL5223S-TP15 (ENTER/NEXT)
D608 8-719-050-84 DIODE RB441Q-40T-77
< FILTER >
FL601 1-517-839-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-589-14 IC TMP88CS76F-6005
IC602 8-759-459-86 IC NJL64H400A
IC603 8-759-083-77 IC BA3830F
IC604 8-759-567-59 IC NJU3716L
< COIL >
L601 1-410-517-11 INDUCTOR 47uH
L602 1-410-517-11 INDUCTOR 47uH
L603 1-410-517-11 INDUCTOR 47uH
L604 1-410-509-11 INDUCTOR 10uH
< LINE FILTER >
LF601 1-424-228-11 FILTER, NOISE
< TRANSISTOR >
Q601 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q602 8-729-118-00 TRANSISTOR 2SB1116-TP-LK
Q603 8-729-118-00 TRANSISTOR 2SB1116-TP-LK
Q605 8-729-029-23 TRANSISTOR DTA114TSA-TP
Q606 8-729-029-23 TRANSISTOR DTA114TSA-TP
Q607 8-729-029-23 TRANSISTOR DTA114TSA-TP
Q608 8-729-047-58 TRANSISTOR DTC114TLTL2
Q609 8-729-047-58 TRANSISTOR DTC114TLTL2
Q610 8-729-047-58 TRANSISTOR DTC114TLTL2
< RESISTOR >
R601 1-247-893-11 CARBON 390K 5% 1/4W
R602 1-247-893-11 CARBON 390K 5% 1/4W
R603 1-249-441-11 CARBON 100K 5% 1/4W
R604 1-249-441-11 CARBON 100K 5% 1/4W
R605 1-247-807-31 CARBON 100 5% 1/4W
R608 1-249-435-11 CARBON 33K 5% 1/4W
R609 1-247-895-91 CARBON 470K 5% 1/4W
R610 1-249-401-11 CARBON 47 5% 1/4W F
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-247-807-31 CARBON 100 5% 1/4W
R613 1-247-807-31 CARBON 100 5% 1/4W
R614 1-247-807-31 CARBON 100 5% 1/4W
R615 1-249-429-11 CARBON 10K 5% 1/4W
R616 1-249-429-11 CARBON 10K 5% 1/4W
R617 1-249-429-11 CARBON 10K 5% 1/4W
R618 1-249-429-11 CARBON 10K 5% 1/4W
R619 1-249-429-11 CARBON 10K 5% 1/4W
R620 1-249-429-11 CARBON 10K 5% 1/4W
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-249-429-11 CARBON 10K 5% 1/4W
DOOR SW FL
