Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
93
1-673-110-11 TRANS BOARD
************
1-533-233-21 HOLDER, FUSE
< CAPACITOR >
C843 1-130-777-00 FILM 0.1uF 10% 100V
C893 1-130-777-00 FILM 0.1uF 10% 100V
C961 1-162-306-11 CERAMIC 0.01uF 30% 16V
C963 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
* CN952 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D832 8-719-060-53 DIODE RBV-2506
< FUSE >
! F951 1-532-505-31 FUSE T5AL/250V (EA,MY,SP,IA)
! F961 1-532-506-31 FUSE T6.3A/250V
! F962 1-532-506-31 FUSE T6.3A/250V
! F963 1-532-506-31 FUSE T6.3A/250V
! F964 1-532-506-31 FUSE T6.3A/250V
< RESISTOR >
! R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
< TRANSFORMER >
! T951 1-433-613-11 TRANSFORMER, POWER
< SWITCH >
! VS901 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(EA,MY,SP,IA)
************************************************************
A-4724-725-A VIDEO BOARD, COMPLETE (EA,MY,SP,IA)
*********************
A-4724-929-A VIDEO BOARD, COMPLETE (TH)
*********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C301 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C302 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C303 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C304 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C305 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C306 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C311 1-216-295-91 SHORT 0
C313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C314 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C318 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C319 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C403 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C404 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C405 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
(EA,MY,SP,IA)
C405 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
(TH)
C406 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
(EA,MY,SP,IA)
C406 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
(TH)
C409 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
(EA,MY,SP,IA)
C409 1-128-996-11 ELECT CHIP 4.7uF 20% 50V
(TH)
C410 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C411 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C412 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C413 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
(EA,MY,SP,IA)
C413 1-126-601-11 ELECT CHIP 2.2uF 20% 50V
(TH)
C452 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C471 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
(TH)
C472 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
(TH)
C501 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C502 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C503 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C547 1-126-193-11 ELECT 1uF 20% 50V
C548 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C549 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C550 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C551 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C552 1-165-319-11 CERAMIC CHIP 0.1uF 50V
TRANS VIDEO
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
To Next Page
